Airtac ACPJ Adjustable Compact Cylinder ACPJ12X100-10SB
2. Front/rear end caps feature threaded connections for enhanced strength and maintenance convenience;
3. Barrel undergoes precision machining followed by hard anodizing treatment for superior wear resistance and durability;
4. Specialized bidirectional sealing structure in piston design ensures compact dimensions with integrated oil reservoir functionality;
5. Space-optimized compact configuration minimizes installation footprint;
6. Perimeter magnetic switch grooves enable flexible sensor mounting options;
7. Multiple standardized mounting accessories available for system integration;
Category: Adjustable Cylinders | Brand: AirTAC | Series: ACPJ
AirTAC ACPJ Adjustable Compact Cylinder ACPJ12X100-10SB Specifications
- Model: ACPJ12X100-10SB
- Type: Single-acting spring return (adjustable stroke)
- Bore size: Φ12mm
- Stroke: 100mm (adjustable range: 0-100mm)
- Operating pressure: 0.15–0.8 MPa
- Cushioning: Adjustable pneumatic cushion
- Mounting type: Standard base mounting (ISO 15552 accessory compatible)
- Port size: M5x0.8
- Stroke adjustment: External screw-type stroke limiter
- Operating temperature: -20℃ to 80℃
- Material: Aluminum alloy body, chrome-plated piston rod
- Seal material: NBR (nitrile rubber)
- Weight: 0.35kg (excluding accessories)
- Dimensions: 150mm(L) × 34mm(W) × 34mm(H) (fully retracted)
Ultra-compact cylinder with precision stroke adjustment capability, featuring a built-in locking mechanism for position fixation. The anodized surface treatment provides corrosion resistance, while the double-sealing structure ensures leak-proof operation. Designed for applications requiring millimeter-level positioning accuracy in confined spaces. Compatible with ISO 15552 mounting accessories for flexible integration.
- Precision workpiece clamping in CNC tool changers
- Micro-positioning in semiconductor handling robots
- Valve actuation in compact analytical instruments
- Packaging machine stopper adjustment systems
- Medical device component positioning
Installation note:
Maximum lateral load 5N. Lubricate piston rod weekly with ISO VG32 hydraulic oil.
For stroke adjustment: Loosen lock nut, turn adjustment screw (1mm per full rotation),
then retighten securely. Avoid exceeding 80% stroke during continuous duty cycles.
| Property | Property Value |
|---|---|
| sku | ACPJ12X100-10SB |
| Adjustable Stroke | <10mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | External Thread |
| Magnet | S-Magnetic |
| Bore Diameter | 12mm |
| Stroke | 100mm |
