Airtac ACPJ Adjustable Compact Cylinder ACPJ12X100-20SB
$51.14
Regular price
$58.64
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
ACPJ12X100-20SB
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Compliant with DIN standards in structural design;
2. Front/rear end caps feature threaded connections for enhanced strength and maintenance convenience;
3. Barrel undergoes precision machining followed by hard anodizing treatment for superior wear resistance and durability;
4. Specialized bidirectional sealing structure in piston design ensures compact dimensions with integrated oil reservoir functionality;
5. Space-optimized compact configuration minimizes installation footprint;
6. Perimeter magnetic switch grooves enable flexible sensor mounting options;
7. Multiple standardized mounting accessories available for system integration;
Category: Adjustable Cylinders | Brand: AirTAC | Series: ACPJ
Installation tip:
Maintain 0.5-1mm clearance between rod end and load during alignment.
Use locknuts (not included) with mounting bolts to prevent loosening
from high-frequency vibrations. Lubricate through port before initial
use if stored >2 years.
Pressure warning:
Do not exceed 1.2MPa burst pressure. Cushion effectiveness reduces
significantly below 0.15MPa - use external dampers for low-pressure
precision applications.
2. Front/rear end caps feature threaded connections for enhanced strength and maintenance convenience;
3. Barrel undergoes precision machining followed by hard anodizing treatment for superior wear resistance and durability;
4. Specialized bidirectional sealing structure in piston design ensures compact dimensions with integrated oil reservoir functionality;
5. Space-optimized compact configuration minimizes installation footprint;
6. Perimeter magnetic switch grooves enable flexible sensor mounting options;
7. Multiple standardized mounting accessories available for system integration;
Category: Adjustable Cylinders | Brand: AirTAC | Series: ACPJ
AirTAC ACPJ Adjustable Compact Cylinder ACPJ12X100-20SB Specifications
- Model: ACPJ12X100-20SB
- Type: Adjustable cushion compact cylinder (double-acting)
- Bore size: Ø12mm
- Stroke: 100mm (customizable 5-300mm)
- Operating pressure: 0.05-1.0 MPa
- Cushion type: Adjustable pneumatic cushion (both ends)
- Mounting style: Basic type (axial mounting)
- Port size: M5x0.8 (standard Rc1/8/NPT1/8 optional)
- Piston material: Aluminum alloy with hard anodization
- Rod material: Stainless steel SUS304
- Seal type: NBR rubber (FDA compliant options available)
- Temperature range: -20℃ to 80℃ (dry air required below 0℃)
- Weight: 0.65kg ±5% (without accessories)
- Dimensions: 150mm(L) × 34mm(W) × 34mm(H) (retracted length)
- Max speed: 500-750mm/s (with cushion adjustment)
- Lubrication: Pre-lubricated (relubrication interval ≥3,000km)
Ultra-slim cylinder featuring micro-adjustable cushioning mechanism with ±30° cushion needle rotation range. Incorporates a wear-resistant chromium-plated rod guide and integrated magnet for position sensing. The 20SB variant includes built-in auto-switch mounting slots (2-M3 threads) for sensor installation.
Industrial Applications:
- PCB handling robots in electronics assembly
- Dosing valve actuation in medical analyzers
- Carton flap control in packaging lines
- Precision clamping devices for CNC fixtures
- Semiconductor wafer transfer mechanisms
Installation tip:
Maintain 0.5-1mm clearance between rod end and load during alignment.
Use locknuts (not included) with mounting bolts to prevent loosening
from high-frequency vibrations. Lubricate through port before initial
use if stored >2 years.
Pressure warning:
Do not exceed 1.2MPa burst pressure. Cushion effectiveness reduces
significantly below 0.15MPa - use external dampers for low-pressure
precision applications.
| Property | Property Value |
|---|---|
| sku | ACPJ12X100-20SB |
| Adjustable Stroke | <20mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | External Thread |
| Magnet | S-Magnetic |
| Bore Diameter | 12mm |
| Stroke | 100mm |
