This model is discontinued
AirTAC has phased out the ACP series. You can still order this code here: we ship the current replacement ACEJ12X100-30, the same code under the new prefix. The ACE replacement is a current-production ISO 21287 compact cylinder in the same bore, stroke and force class, with a matching short body and the same mounting-accessory family, so it fits the same envelope. Confirm mounting-interface dimensions against the ACE datasheet before ordering.
Airtac ACPJ Adjustable Compact Cylinder ACPJ12X100-30
The AirTAC ACPJ Adjustable Compact Cylinder ACPJ12X100-30 is a double acting, double rod, adjustable stroke DIN-standard tight/compact air cylinder with a Ø12mm bore and 100mm stroke, M5×0.8 air ports and a hard-anodized aluminium body. This model is discontinued — the current-production replacement is the ACEJ12X100-30 (ISO 21287 ACE), in the same bore, stroke and force class.
- BoreØ12 mm
- Stroke100 mm
- Port sizeM5×0.8
- Acting typeDouble acting, double rod, adjustable stroke
- Rod threadM3×0.5
- StatusDiscontinued → ACEJ12X100-30
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac ACPJ Adjustable Compact Cylinder ACPJ12X100-30
The ACPJ12X100-30 is a double acting compact cylinder with an adjustable extend stroke: the -30 code gives a 30 mm stop-screw window, so the 100 mm stroke can be trimmed anywhere in a 70-100 mm range on site. Air works on both sides of the 12 mm piston, delivering 56.5 N push and 42.4 N pull at 0.5 MPa (79.2 N / 59.4 N at 0.7 MPa), with a theoretical peak of 11.5 kgf at 1.0 MPa. As a rule of thumb, plan on roughly 33.9 N of real work at 0.5 MPa, which is about 2.9 kg of vertical lift with a 2:1 margin. Note the 100 mm stroke exceeds the 50 mm maximum standard stroke for bore 12, so this unit is made to order.
This model is discontinued; the current-production replacement is the ACEJ12X100, which swaps the P for an E and matches the same bore, stroke and force class in the ISO 21287 family - confirm the ISO 21287 mounting dimensions before swapping, since the ACP is DIN-standard. The short hard-anodized aluminium body saves about 50% of the mounting length of an ISO 15552 profile cylinder, and a fixed TPU bumper sits at both ends. No magnet is fitted on this version (the optional -S code adds one for CMSE / DMSE switches), the rod end is female M3x0.5, the port is M5x0.8, and speed runs 30-500 mm/s at 0.15-1.0 MPa (22-145 psi).
Airtac ACPJ Adjustable Compact Cylinder ACPJ12X100-30 Technical Specifications
| Model | Airtac ACPJ Adjustable Compact Cylinder ACPJ12X100-30 |
|---|---|
| Series | ACPJ DIN compact cylinder (discontinued) |
| Replacement | ACEJ12X100-30 |
| Bore size | Ø12 mm |
| Stroke | 100 mm |
| Acting type | Double acting, double rod, adjustable stroke |
| Port size | M5×0.8 |
| Rod thread | M3×0.5 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Fixed bumper (both ends) |
| Max standard stroke | Up to 50 mm |
Specifications follow the official AirTAC ACP datasheet (now discontinued). The ACEJ12X100-30 (ISO 21287) carries the same bore/stroke/force class; confirm mounting-interface dimensions against the ACE datasheet before installation. Rod type: female thread (blank) or male thread (B). Thread options: PT (blank) / G.
Theoretical Output Force (Ø12mm)
| Pressure | Force (both ways) |
|---|---|
| 0.5 MPa | 42 N |
| 0.7 MPa | 59 N |
| Max (@1.0 MPa) | 9 kgf |
ACPJ is double-rod: the rear rod that carries the stroke adjuster exits the rear cover, so both piston faces lose rod area. The rod-side (annular) area is used for both directions (conservative).
Model Code: Airtac ACPJ Adjustable Compact Cylinder ACPJ12X100-30
| ACPJ | DIN compact cylinder (adjustable-stroke, discontinued). |
|---|---|
| 12 | Bore size in mm. |
| ×100 | Stroke length in mm. |
| -30 | Adjustable stroke window (mm the extend stroke can be shortened on site). |
| S | Optional built-in magnet for sensor position sensing (omit for no magnet). |
| B | Rod type: B = male thread; blank = female thread. |
Replacement mapping (swap P for E): ACP→ACE, ASP→ASE, ATP→ATE, ACPD→ACED, ACPJ→ACEJ. ACP-family: ACP (double acting), ASP / ATP (single acting push / pull), ACPD (double rod), ACPJ (double rod, adjustable stroke).
Where the Airtac ACPJ Adjustable Compact Cylinder ACPJ12X100-30 Is Used
Small-parts ejection in assembly fixtures
The 70-100 mm trim range lets a fixture builder dial in the exact eject length for connector or PCB push-off stations, with 56.5 N at 0.5 MPa enough for light plastic parts.
Compact slide check in test rigs
Order the -S version when a CMSE or DMSE switch must confirm end positions inside a tight test head; this standard build has no magnet fitted.
Light vertical lift in a packaging head
With about 2.9 kg of practical vertical lift at 0.5 MPa, the 12 mm bore suits lowering a small weigh head or nozzle into a carton, trimmed by the 30 mm stop window.
Replacing the Airtac ACPJ Adjustable Compact Cylinder ACPJ12X100-30 with the ACEJ12X100-30
Bore 12 is the smallest in this family, so if 56.5 N push at 0.5 MPa is marginal for your jig, step up to bore 16 (100.5 N push / 75.4 N pull at 0.5 MPa) rather than pushing this bore to its limit. The stop screw only shortens the extend stroke within the ordered 30 mm window and is a mechanical end stop, not a mid-stroke lock - the rod still drifts if air is lost, so add a separate clamp if you must hold position. FA/FB flange and LB foot mounts bolt to the ISO 21287 face. For new designs, order the ACEJ12X100 instead, as this ACPJ version is discontinued.
Replacement checklist
- ✓ Current-production ACE → ACEJ12X100-30
- ✓ Same bore / stroke / force class
- ✓ Confirm ISO 21287 mounting dimensions
- ✓ Port/thread type (PT / G)
- ✓ Add -S for magnet if you need sensors
Airtac ACPJ Adjustable Compact Cylinder ACPJ12X100-30 FAQ
At 0.5 MPa it pushes 56.5 N and pulls 42.4 N; at 0.7 MPa it pushes 79.2 N and pulls 59.4 N; theoretical maximum is 11.5 kgf at 1.0 MPa. The -30 code gives a 30 mm adjustment window, so the 100 mm extend stroke can be shortened to any length from 70 to 100 mm with the stop screw. It is double acting, runs 30-500 mm/s at 0.15-1.0 MPa (22-145 psi), and the 100 mm stroke is a made-to-order length because bore 12 normally tops out at 50 mm.
Order the ACEJ12X100, the current-production ISO 21287 successor: swap the P for an E and you get the same 12 mm bore, 100 mm stroke and force class in a matching short body. Check the ISO 21287 mounting dimensions against your fixture before swapping, since the ACPJ was built to the older DIN-standard compact format. Also confirm whether you need the optional -S magnet for CMSE / DMSE switches, and remember the TPU bumper is a fixed end pad, not a load-holding device.
