This model is discontinued
AirTAC has phased out the ACP series. You can still order this code here: we ship the current replacement ACEJ12X100-30B, the same code under the new prefix. The ACE replacement is a current-production ISO 21287 compact cylinder in the same bore, stroke and force class, with a matching short body and the same mounting-accessory family, so it fits the same envelope. Confirm mounting-interface dimensions against the ACE datasheet before ordering.
Airtac ACPJ Adjustable Compact Cylinder ACPJ12X100-30B
The AirTAC ACPJ Adjustable Compact Cylinder ACPJ12X100-30B is a double acting, double rod, adjustable stroke DIN-standard tight/compact air cylinder with a Ø12mm bore and 100mm stroke, M5×0.8 air ports and a hard-anodized aluminium body. This model is discontinued — the current-production replacement is the ACEJ12X100-30B (ISO 21287 ACE), in the same bore, stroke and force class.
- BoreØ12 mm
- Stroke100 mm
- Port sizeM5×0.8
- Acting typeDouble acting, double rod, adjustable stroke
- Rod threadM3×0.5
- StatusDiscontinued → ACEJ12X100-30B
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac ACPJ Adjustable Compact Cylinder ACPJ12X100-30B
This double acting compact cylinder carries a 12 mm bore with a 100 mm stroke and a male rod thread (the B code). A stop screw trims the extend stroke anywhere inside the ordered 30 mm window, giving a usable range of 70-100 mm without changing the air supply. At 0.5 MPa it pushes 56.5 N and pulls 42.4 N; at 0.7 MPa those rise to 79.2 N and 59.4 N, with a theoretical maximum of 11.5 kgf at 1.0 MPa. The 100 mm stroke exceeds the 50 mm standard maximum for bore 12, so it is a non-standard, made-to-order length. Note the ACPJ family is discontinued: the current-production drop-in is the ACEJ12X100 in the same bore, stroke and force class.
The short ISO 21287-class body saves about 50% of the mounting length of an ISO 15552 profile cylinder, so it slots into slim jigs and guarded stations where a full-length body will not fit. A fixed TPU bumper sits at both ends. Plan on roughly 34 N (about 3.5 kgf) of real work at 0.5 MPa, which lifts roughly 2.9 kg vertically with a 2:1 margin. No magnet is fitted on this version, so no CMSE or DMSE switch can be mounted; order the optional -S code if sensing is needed. Running spec: 0.15-1.0 MPa (22-145 psi), 30-500 mm/s, air filtered to 40 um, -20 to +70 C.
Airtac ACPJ Adjustable Compact Cylinder ACPJ12X100-30B Technical Specifications
| Model | Airtac ACPJ Adjustable Compact Cylinder ACPJ12X100-30B |
|---|---|
| Series | ACPJ DIN compact cylinder (discontinued) |
| Replacement | ACEJ12X100-30B |
| Bore size | Ø12 mm |
| Stroke | 100 mm |
| Acting type | Double acting, double rod, adjustable stroke |
| Port size | M5×0.8 |
| Rod thread | M3×0.5 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Fixed bumper (both ends) |
| Max standard stroke | Up to 50 mm |
Specifications follow the official AirTAC ACP datasheet (now discontinued). The ACEJ12X100-30B (ISO 21287) carries the same bore/stroke/force class; confirm mounting-interface dimensions against the ACE datasheet before installation. Rod type: female thread (blank) or male thread (B). Thread options: PT (blank) / G.
Theoretical Output Force (Ø12mm)
| Pressure | Force (both ways) |
|---|---|
| 0.5 MPa | 42 N |
| 0.7 MPa | 59 N |
| Max (@1.0 MPa) | 9 kgf |
ACPJ is double-rod: the rear rod that carries the stroke adjuster exits the rear cover, so both piston faces lose rod area. The rod-side (annular) area is used for both directions (conservative).
Model Code: Airtac ACPJ Adjustable Compact Cylinder ACPJ12X100-30B
| ACPJ | DIN compact cylinder (adjustable-stroke, discontinued). |
|---|---|
| 12 | Bore size in mm. |
| ×100 | Stroke length in mm. |
| -30 | Adjustable stroke window (mm the extend stroke can be shortened on site). |
| S | Optional built-in magnet for sensor position sensing (omit for no magnet). |
| B | Rod type: B = male thread; blank = female thread. |
Replacement mapping (swap P for E): ACP→ACE, ASP→ASE, ATP→ATE, ACPD→ACED, ACPJ→ACEJ. ACP-family: ACP (double acting), ASP / ATP (single acting push / pull), ACPD (double rod), ACPJ (double rod, adjustable stroke).
Where the Airtac ACPJ Adjustable Compact Cylinder ACPJ12X100-30B Is Used
Small-part ejection in a plastic molding cell
The 56.5 N push at 0.5 MPa is enough to strip tiny molded caps off a core pin, and the 30 mm window lets the operator trim the 100 mm stroke down to 70 mm so the ejector never bottoms out.
Presence check on an electronics assembly line
A light push probe verifies a connector is seated before soldering; the male rod thread (B code) takes a custom probe tip, and the 70-100 mm adjustable range adapts to different fixture heights.
Low-profile gate latch on a compact machine guard
The short body, roughly 50% shorter in mounting length than an ISO 15552 profile cylinder, fits inside the guard frame, and the 2.9 kg vertical-lift margin comfortably swings a lightweight latch arm.
Replacing the Airtac ACPJ Adjustable Compact Cylinder ACPJ12X100-30B with the ACEJ12X100-30B
At 56.5 N push (0.5 MPa) this bore suits light clamping and part-present checks; step up to the 16 mm bore (100.5 N) or 20 mm bore (157.1 N) if the load is heavier. The adjuster is a mechanical end stop for the extend stroke only - it does not lock the piston mid-stroke, and on air loss the rod still drifts, so do not use it to hold a load. FA/FB flange and LB foot mountings bolt to the standard face. Confirm the ISO 21287 mounting dimensions of the ACEJ12X100 before swapping from this discontinued model.
Replacement checklist
- ✓ Current-production ACE → ACEJ12X100-30B
- ✓ Same bore / stroke / force class
- ✓ Confirm ISO 21287 mounting dimensions
- ✓ Port/thread type (PT / G)
- ✓ Add -S for magnet if you need sensors
Airtac ACPJ Adjustable Compact Cylinder ACPJ12X100-30B FAQ
At 0.5 MPa it pushes 56.5 N and pulls 42.4 N; at 0.7 MPa it pushes 79.2 N and pulls 59.4 N; theoretical maximum is 11.5 kgf at 1.0 MPa. The -30 code gives a 30 mm adjustment window, so the extend stroke can be trimmed anywhere from 70 mm to the full 100 mm with a stop screw. The 100 mm stroke is non-standard for bore 12 (standard maximum is 50 mm), so it is made to order. Speed range is 30-500 mm/s at 0.15-1.0 MPa (22-145 psi).
Only if the optional -S magnet was ordered - this version has no magnet, so CMSE or DMSE reed or solid-state switches cannot be fitted as-is. The ACPJ family is discontinued; the current-production replacement is the ACEJ12X100, a drop-in successor in the same bore, stroke and force class. Confirm the ISO 21287 mounting dimensions before swapping, since the ACP was built to a DIN-standard footprint.
