Airtac ACPJ Adjustable Compact Cylinder ACPJ12X100-40B
2. Front/rear end caps feature threaded connections for enhanced strength and maintenance convenience;
3. Barrel undergoes precision machining followed by hard anodizing treatment for superior wear resistance and durability;
4. Specialized bidirectional sealing structure in piston design ensures compact dimensions with integrated oil reservoir functionality;
5. Space-optimized compact configuration minimizes installation footprint;
6. Perimeter magnetic switch grooves enable flexible sensor mounting options;
7. Multiple standardized mounting accessories available for system integration;
Category: Adjustable Cylinders | Brand: AirTAC | Series: ACPJ
AirTAC ACPJ Adjustable Compact Cylinder ACPJ12X100-40B Specifications
- Model: ACPJ12X100-40B
- Type: Double-acting adjustable compact cylinder
- Bore size: 12mm
- Stroke: 100mm (±0.5mm tolerance)
- Adjustable cushioning: Front & rear stroke-end cushioning
- Operating pressure: 0.15–0.8 MPa (21.7–116 psi)
- Temperature range: -20℃ to 80℃ (non-freezing)
- Port size: PT1/8 (G1/8 optional)
- Mounting style: Basic type (standard flange)
- Piston material: Aluminum alloy with hard anodizing
- Rod material: SUS304 stainless steel
- Seal material: NBR (nitrile rubber)
- Weight: 0.6kg (1.32 lbs)
- Dimensions: 140mm(L) × 40mm(W) × 40mm(H) (5.51"×1.57"×1.57")
- Max theoretical thrust: 7.2kgf at 0.5MPa
- Air consumption: 7.3cm³/stroke
- Protection rating: IP65 (dust-tight & water jet resistant)
Ultra-slim profile cylinder featuring micrometer-grade cushion adjustment knobs for precise motion control. Incorporates wear-resistant guide bushings and self-lubricating seals. The 40B suffix indicates built-in auto-switch compatibility with 3-wire NPN/PNP sensors (not included). Requires ISO 8573-1:2010 Class 4 compressed air.
- PCB handling robots in electronics manufacturing
- Pharmaceutical blister packaging machines
- Micro-positioning stages in optical equipment
- Automated test jigs with space constraints
- Medical device assembly systems
Installation tips:
Use M4×0.7 mounting screws with 8.8 grade or higher.
For vertical mounting, install rod-end down to prevent debris accumulation.
Adjust cushion screws in 1/4-turn increments during commissioning.
| Property | Property Value |
|---|---|
| sku | ACPJ12X100-40B |
| Adjustable Stroke | <40mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | External Thread |
| Magnet | Non-magnetic |
| Bore Diameter | 12mm |
| Stroke | 100mm |
