Airtac ACPJ Adjustable Compact Cylinder ACPJ12X100-40S
2. Front/rear end caps feature threaded connections for enhanced strength and maintenance convenience;
3. Barrel undergoes precision machining followed by hard anodizing treatment for superior wear resistance and durability;
4. Specialized bidirectional sealing structure in piston design ensures compact dimensions with integrated oil reservoir functionality;
5. Space-optimized compact configuration minimizes installation footprint;
6. Perimeter magnetic switch grooves enable flexible sensor mounting options;
7. Multiple standardized mounting accessories available for system integration;
Category: Adjustable Cylinders | Brand: AirTAC | Series: ACPJ
AirTAC ACPJ12X100-40S Adjustable Compact Cylinder Specifications
- Model: ACPJ12X100-40S
- Type: Adjustable cushion compact cylinder (double acting)
- Bore size: Ø12mm (actual piston diameter: 12.7mm)
- Stroke: 100mm (±0.5mm tolerance)
- Operating pressure: 0.15–0.8 MPa (21.7–116 psi)
- Cushion type: Adjustable pneumatic cushion (both ends)
- Mounting style: Foot mounting (ISO 15552 standard)
- Port size: M5×0.8 (Rc1/8/NPT1/8 optional)
- Temperature range: -20℃ to 80℃ (dry air required below 0℃)
- Piston material: Aluminum alloy with hard anodized surface
- Rod material: Stainless steel (SUS304)
- Seal material: NBR (Nitrile rubber)
- Weight: 0.45kg (excluding accessories)
- Dimensions: 160mm(L) × 40mm(W) × 52mm(H)
- Max theoretical force: 10.1kgf@0.8MPa (extending)
- Air consumption: 12.7cm³ per 1mm stroke
- Lubrication: Pre-lubricated (Do not mix with petroleum-based oils)
Ultra-slim profile cylinder featuring dual adjustable air cushions for precise end position control. The precision-ground piston rod with multi-lip seals ensures ≤0.5mm/s creep speed under load. Integrated mounting slots allow tool-free position adjustment. Designed for high cycle rates up to 3,000 cycles/hour with proper lubrication.
- PCB handling robots in electronics assembly
- Precision clamping mechanisms in CNC tool changers
- Cartesian coordinate actuators for pick-and-place systems
- Medical device positioning stages
- Compact packaging machine pushers
Installation note:
Maintain 0.5mm minimum clearance between cylinder body and machine frame.
Use copper-based anti-seize compound on threaded parts. For vertical mounting,
install with rod end downward to prevent condensate accumulation.
| Property | Property Value |
|---|---|
| sku | ACPJ12X100-40S |
| Adjustable Stroke | <40mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | Internal Thread |
| Magnet | S-Magnetic |
| Bore Diameter | 12mm |
| Stroke | 100mm |
