Airtac ACPJ Adjustable Compact Cylinder ACPJ12X100-40SB
The AirTAC ACPJ Adjustable Compact Cylinder ACPJ12X100-40SB is a double acting, double rod, adjustable stroke DIN-standard tight/compact air cylinder with a Ø12mm bore and 100mm stroke, M5×0.8 air ports and a hard-anodized aluminium body. This model is discontinued — the current-production replacement is the ACEJ12X100-40SB (ISO 21287 ACE), in the same bore, stroke and force class.
- BoreØ12 mm
- Stroke100 mm
- Port sizeM5×0.8
- Acting typeDouble acting, double rod, adjustable stroke
- Rod threadM3×0.5
- StatusDiscontinued → ACEJ12X100-40SB
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac ACPJ Adjustable Compact Cylinder ACPJ12X100-40SB
The ACPJ12X100-40SB is a double acting compact cylinder with an adjustable extend stroke: the -40 stop screw trims the 100 mm stroke anywhere inside a 40 mm window, giving a usable range of 60-100 mm. Air works on both faces of the 12 mm piston, so the rod extends with 56.5 N and retracts with 42.4 N at 0.5 MPa, rising to 79.2 N on the push stroke at 0.7 MPa. The 100 mm stroke exceeds the 50 mm standard limit for bore 12, so this unit is a made-to-order build. Note that this ACPJ model is discontinued; the current-production successor is the ACEJ12X100, and buyers should confirm the ISO 21287 mounting dimensions before swapping, since the ACP series was built to a DIN-standard footprint.
The short ISO 21287-class body saves roughly 50% of the mounting length of an ISO 15552 profile cylinder, which is why it slots into slim jigs, small gating brackets and cramped test fixtures. In practice, plan on about 34 N of real work at 0.5 MPa (roughly 60% of the rated push), and expect it to lift about 2.9 kg vertically once a 2:1 margin is applied. The -S code on this model means the position magnet is fitted, so CMSE or DMSE reed and solid-state switches can be clamped straight onto the hard-anodized aluminium body. A fixed TPU bumper sits at each end, the S45C rod carries a hard-chrome finish with a male thread, and speed runs 30-500 mm/s across 0.15-1.0 MPa (22-145 psi).
Airtac ACPJ Adjustable Compact Cylinder ACPJ12X100-40SB Technical Specifications
| Model | Airtac ACPJ Adjustable Compact Cylinder ACPJ12X100-40SB |
|---|---|
| Series | ACPJ DIN compact cylinder (discontinued) |
| Replacement | ACEJ12X100-40SB |
| Bore size | Ø12 mm |
| Stroke | 100 mm |
| Acting type | Double acting, double rod, adjustable stroke |
| Port size | M5×0.8 |
| Rod thread | M3×0.5 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Fixed bumper (both ends) |
| Max standard stroke | Up to 50 mm |
Specifications follow the official AirTAC ACP datasheet (now discontinued). The ACEJ12X100-40SB (ISO 21287) carries the same bore/stroke/force class; confirm mounting-interface dimensions against the ACE datasheet before installation. Rod type: female thread (blank) or male thread (B). Thread options: PT (blank) / G.
Theoretical Output Force (Ø12mm)
| Pressure | Force (both ways) |
|---|---|
| 0.5 MPa | 42 N |
| 0.7 MPa | 59 N |
| Max (@1.0 MPa) | 9 kgf |
ACPJ is double-rod: the rear rod that carries the stroke adjuster exits the rear cover, so both piston faces lose rod area. The rod-side (annular) area is used for both directions (conservative).
Model Code: Airtac ACPJ Adjustable Compact Cylinder ACPJ12X100-40SB
| ACPJ | DIN compact cylinder (adjustable-stroke, discontinued). |
|---|---|
| 12 | Bore size in mm. |
| ×100 | Stroke length in mm. |
| -40 | Adjustable stroke window (mm the extend stroke can be shortened on site). |
| S | Optional built-in magnet for sensor position sensing (omit for no magnet). |
| B | Rod type: B = male thread; blank = female thread. |
Replacement mapping (swap P for E): ACP→ACE, ASP→ASE, ATP→ATE, ACPD→ACED, ACPJ→ACEJ. ACP-family: ACP (double acting), ASP / ATP (single acting push / pull), ACPD (double rod), ACPJ (double rod, adjustable stroke).
Where the Airtac ACPJ Adjustable Compact Cylinder ACPJ12X100-40SB Is Used
Compact lab test stations
The 60-100 mm adjustable window and 56.5 N push at 0.5 MPa suit small sample-clamping actuators on bench-top leak and fatigue rigs where every millimetre of length counts.
Micro-part ejection on assembly fixtures
With about 34 N of practical working force and a 6 mm male-thread rod, this cylinder punches tiny stamped or moulded parts out of shallow nests in electronics assembly tooling.
Position-verified slide gates
Because the -S magnet is fitted, CMSE or DMSE switches confirm gate open/closed states on small diverters and inspection shutters, with the stop screw set anywhere from 60 to 100 mm of travel.
Replacing the Airtac ACPJ Adjustable Compact Cylinder ACPJ12X100-40SB with the ACEJ12X100-40SB
Bore 12 is the smallest in this family: at 0.5 MPa it pushes 56.5 N and pulls 42.4 N, so if your load needs more, step up to bore 16 (100.5 N push) or bore 20 (157.1 N push) in the same compact envelope. The -40 adjuster is a mechanical end stop for the extend stroke only - it does not hold a load if air pressure is lost, so add a separate locking valve where that matters. This version has a male rod thread (B) and PT ports; FA/FB flange or LB foot mounts bolt to the standard face. If you are designing new tooling, specify the ACEJ12X100 instead, as the ACPJ line is discontinued.
Replacement checklist
- ✓ Current-production ACE → ACEJ12X100-40SB
- ✓ Same bore / stroke / force class
- ✓ Confirm ISO 21287 mounting dimensions
- ✓ Port/thread type (PT / G)
- ✓ Add -S for magnet if you need sensors
Airtac ACPJ Adjustable Compact Cylinder ACPJ12X100-40SB FAQ
At 0.5 MPa it pushes 56.5 N and pulls 42.4 N; at 0.7 MPa those figures rise to 79.2 N push and 59.4 N pull, with a theoretical maximum of 11.5 kgf at 1.0 MPa. The -40 code gives a 40 mm adjustment window, so the extend stroke can be trimmed anywhere between 60 and 100 mm. The 100 mm stroke is a made-to-order length because bore 12 tops out at 50 mm as a standard stroke. Operating range is 0.15-1.0 MPa (22-145 psi) at 30-500 mm/s.
It is a short-body compact cylinder whose hard-anodized aluminium body saves about 50% of the mounting length of an ISO 15552 profile cylinder, with a fixed TPU bumper at each end and an M5x0.8 port. The -S magnet on this unit accepts CMSE and DMSE switches for end-position sensing. The ACPJ family is no longer in production: order the ACEJ12X100, the current ISO 21287 drop-in in the same bore and stroke class, and confirm the mounting dimensions against your fixture before the swap.
