Airtac X-AHVFS Hand Valve X-AHVFS0801B
AirTAC X-AHVFS0801B Manual Valve Technical Details
- Model: X-AHVFS0801B
- Type: 3/2-way manual push-pull valve (spring return)
- Port size: PT1/4 (G1/8 adapter compatible)
- Operating pressure: 0.05–0.85 MPa
- Flow capacity: 500 NL/min (at 0.5 MPa)
- Manual operation force: ≤20 N
- Body material: Anodized aluminum alloy
- Seal material: High-grade NBR (nitrile rubber)
- Temperature range: -20℃ to 80℃
- Weight: 0.28 kg (without fittings)
- Dimensions: 68mm(L) × 38mm(W) × 95mm(H)
- Mounting: Panel mount with M5 screws
- Port thread depth: 12mm engagement
- Pressure proof: 1.3 MPa (maximum burst pressure)
Robust manual override valve featuring ergonomic toggle design with positive tactile feedback. The hardened stainless steel shaft and triple-lip seal configuration ensure leak-free operation in high-cycle applications. Integrated dust cap protects actuator mechanism in harsh environments.
- Emergency override in automated production lines
- Maintenance bypass for pneumatic system troubleshooting
- Manual control in material handling equipment
- Test bench pressure regulation systems
- Safety interlocks for industrial machinery
Installation guidelines:
Requires ISO 8573-1:2010 Class 3 compressed air (max 5mg/m³ oil content).
For vertical mounting, install exhaust port downward to prevent debris accumulation.
Lubricate pivot points every 5,000 cycles using ISO VG32 pneumatic oil.
| Property | Property Value |
|---|---|
| sku | X-AHVFS0801B |
