Airtac X-AHVFS Hand Valve X-AHVFS1004B
AirTAC X-AHVFS1004B Manual Valve Specifications
- Model: X-AHVFS1004B
- Type: 2-position, 5-way manual operated valve
- Port size: 1/4" NPT (G1/8 optional)
- Operating pressure: 0.2–1.0 MPa
- Max flow rate: 800 NL/min (ANR)
- Actuation method: Lever-operated with mechanical lock
- Body material: Anodized aluminum alloy (ISO 6358 compliant)
- Seal material: HNBR (Hydrogenated Nitrile) with PTFE coating
- Temperature range: -10℃ to 80℃ (non-freezing conditions)
- Weight: 485g ±5g
- Dimensions: 78mm(L) × 34mm(W) × 42mm(H)
- Port thread depth: 12mm (minimum engagement 9mm)
- Operating force: ≤3.5N at 0.6MPa
- Leakage rate: ≤5 bubbles/min (JIS B8379 test standard)
- Compatible fluids: Clean compressed air (ISO 8573-1:2010 Class 3.4.2)
Industrial-grade manual override valve with positive center position lock, designed for emergency operation or maintenance bypass in automated systems. Features anti-corrosion treatment and ergonomic lever design with tactile feedback. Includes dual-stage sealing system for pressure retention during power outages.
- Production line emergency stop systems
- Pneumatic cylinder manual positioning in CNC machinery
- Batch processing equipment maintenance override
- Material handling system troubleshooting
- Robotic arm safety lockout procedures
Installation guidelines:
Mount in accessible locations with lever movement clearance ≥60° arc.
Use thread sealant on male ports (PTFE tape not recommended).
Perform monthly lever cycling to maintain seal lubrication distribution.
