Airtac B01-MAC Series Special Purpose Cylinder B01-MAC16X200SCA
AirTAC B01-MAC16X200SCA Specialty Cylinder Specifications
- Model: B01-MAC16X200SCA
- Type: Compact round-body single-acting spring-return cylinder
- Bore size: 16mm (ISO 6432 standard)
- Stroke: 200mm (±0.5mm tolerance)
- Operating pressure: 0.05–1.0 MPa
- Operating temperature: -20℃ to 80℃
- Piston speed: 50–800 mm/s
- Cushioning: Adjustable rubber buffer
- Mounting types: MF1 (front flange), MB1 (rear pivot)
- Port size: M5x0.8 (standard), G1/8 optional
- Rod material: Chrome-plated steel (SUS304)
- Tube material: Anodized aluminum alloy
- Seal material: NBR (Nitrile rubber)
- Weight: 0.65kg (excluding accessories)
- Dimensions: 260mm(L) × 50mm(W) × 50mm(H) (full extension)
- ISO certification: 6432/DIS 15552 compliant
Precision-engineered compact cylinder featuring anti-rotation mechanism for vertical applications. The chrome-plated piston rod with triple sealing system ensures leak-free operation in high-cycle environments. Integrated shock absorbers reduce end-impact noise by 40% compared to standard models.
- PCB handling robots in electronics manufacturing
- Pharmaceutical blister packaging machines
- Automated door locking mechanisms
- Textile machinery thread control systems
- Solar panel cleaning actuator arms
Installation note:
Lubricate with ISO VG32 hydraulic oil before initial use.
For vertical mounting, ensure rod end faces downward to prevent
condensate accumulation. Max side load: 15N at full extension.
| Property | Property Value |
|---|---|
| sku | B01-MAC16X200SCA |
