Airtac B01-MAC Series Special Purpose Cylinder B01-MAC16X250SCA
AirTAC B01-MAC16X250SCA Special Purpose Cylinder Specifications
- Model: B01-MAC16X250SCA
- Type: Single-acting spring return (pneumatic spring extended)
- Bore size: 16mm
- Stroke: 250mm
- Operating pressure: 0.05–0.9 MPa
- Temperature range: -20℃ to 80℃
- Port size: M5x0.8 (dual ports)
- Cushioning: Adjustable air cushion at both ends
- Mounting type: Basic front flange (ISO 15552 standard)
- Rod material: Hard chrome-plated steel
- Tube material: Anodized aluminum alloy
- Seal material: NBR (nitrile rubber)
- Weight: Approx. 1.25kg
- Dimensions: 298mm(L) × 40mm(W) × 40mm(H)
- Piston speed: 50–800mm/s (lubricated condition)
- Protection rating: IP54 (standard wiper seal)
A high-precision industrial cylinder featuring optimized air consumption and smooth stroke control. The nickel-plated piston rod resists chemical corrosion in harsh environments. Spring chamber incorporates dust-resistant design with integrated scraper. Requires ISO VG32 hydraulic oil mist lubrication for optimal performance.
- PCB board clamping in electronics manufacturing
- Precision dosing mechanisms in pharmaceutical packaging
- Automated palletizing systems
- Textile machinery thread tension control
- Beverage canning line actuators
Installation guidance:
Mount with 0.05mm maximum misalignment tolerance. For vertical installations,
use spring chamber downward position to prevent moisture accumulation.
Lubricate every 3 months under normal operation (500 cycles/day).
| Property | Property Value |
|---|---|
| sku | B01-MAC16X250SCA |
