Airtac CM3PF Flat Push Button Mechanical Valve CM3PF08G
1. CM3B, CM3L, CM3V, and CM3R series require external force for directional switching, suitable for position detection or limit switch applications.
2. CM3PF, CM3PM, CM3PMS, CM3PMX, CM3PL, CM3PP, CM3HS, CM3HD, and CM3Y series feature manual operation with multi-configuration actuator heads for diverse operational conditions.
3. Shut-off type structure ensures excellent sealing performance, responsive direction switching, and lubrication-free operation.
4. Multi-position mounting capability enables flexible installation configurations.
5. CM3L, CM3V, CM3R, and CM3Y series incorporate metal actuator heads for enhanced durability and operational stability.
6. CM3PMS and CM3PMX series integrate metal protective covers to safeguard button caps and prevent accidental activation from external forces.
Category: Mechanical Valves | Brand: AirTAC | Series: CM3PF
AirTAC CM3PF Flat-Head Push Button Mechanical Valve CM3PF08G Specifications
- Model: CM3PF08G
- Type: 3/2-way manual reset mechanical valve (spring return)
- Port size: G1/8 (ISO228 standard)
- Operating pressure range: 0.05–1.0 MPa
- Max flow rate: 750 L/min (ANR)
- Actuation force: 30N ±5N
- Body material: Aluminum alloy (hard anodized surface)
- Seal material: HNBR rubber (-20℃ to 120℃)
- Weight: 205g ±5g
- Dimensions: 40mm(L) × 36mm(W) × 54mm(H)
- Mounting: Direct panel mounting (M5 threaded holes)
- Protection rating: IP67 (dust/water resistant)
- Cycle life: ≥500,000 operations
Robust mechanical emergency stop valve with tactile feedback, featuring a low-profile 12mm mushroom head for quick activation. The chrome-plated steel spring ensures reliable resetting, while the dual O-ring design prevents accidental engagement. Compatible with ISO 13850 safety standards for machinery applications.
- Emergency stop circuits in CNC machines
- Safety interlocks for automated production lines
- Manual override systems in packaging machinery
- Process control in semiconductor manufacturing equipment
- Mobile hydraulic platform safety controls
Installation note:
Mount with 50mm minimum spacing between adjacent valves. Apply thread sealant
(PTFE tape recommended) on port connections. Test actuation force monthly using
calibrated force gauge (25-35N range).
- Lubricate pivot points with ISO VG32 hydraulic oil every 6 months
- Inspect seal integrity after 100k cycles or 2 years (whichever comes first)
- Replace entire unit if housing shows visible deformation >0.5mm
