Airtac MALJ25 Adjustable Mini Air Cylinder MALJ25X100-30
2. Front/rear end covers feature threaded connections for secure assembly and maintenance;
3. Specially designed bi-directional piston seal structure with compact design and integrated oil reservoir functionality;
4. Front end incorporates self-lubricating bearings for smooth guiding and low friction operation;
5. Multiple rear mounting configurations (base, pivot, flange) for flexible installation solutions;
6. Comprehensive range of cylinder accessories and mounting brackets available for customized pneumatic system integration.
Category: Adjustable Cylinders , Brand: Airtac , Series: MALJ25
AirTAC MALJ25X100-30 Adjustable Miniature Cylinder Specifications
- Model: MALJ25X100-30
- Type: Double-acting adjustable stroke cylinder
- Bore size: 25mm
- Stroke: 100mm (adjustable range: ±3mm via built-in stroke adjuster)
- Operating pressure: 0.05–0.8 MPa
- Cushioning: Adjustable pneumatic cushioning
- Mounting style: Standard NAMUR mounting with 4x M5 threaded holes
- Port size: M5x0.8 (G1/8 adaptor included)
- Piston rod material: Hard chrome-plated steel
- Tube material: Anodized aluminum alloy
- Seal material: NBR (Nitrile rubber)
- Temperature range: -20℃ to 80℃
- Weight: 0.68kg (with standard accessories)
- Dimensions:
- Extended length: 182mm
- Retracted length: 82mm
- Body diameter: 32mm
- Rod end thread: M6x1.0
Ultra-compact cylinder featuring micro-adjustment capability (±3mm stroke fine-tuning) through integrated mechanical stops. The precision-ground piston rod and double-seal design ensure leak-free operation in high-cycle applications. Includes shock-absorbing cushions at both ends to minimize impact noise. Compatible with ISO 21287 compact cylinder standards.
- Precision clamping in PCB assembly fixtures
- Micro-positioning in semiconductor handling robots
- Valve actuation in medical fluid control systems
- Packaging machine stopper adjustment mechanisms
- Automated test equipment with space constraints
Installation notes:
- Use locknuts (not included) for rod end load connection
- Lubricate with ISO VG32 turbine oil if operating below -10℃
- Max side load: 15N at full extension
- For vertical mounting, add external guide mechanism
| Property | Property Value |
|---|---|
| sku | MALJ25X100-30 |
| Adjustable Stroke | 30mm |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Bore Diameter | <25 mm> |
| Stroke | 100mm |
