Airtac S3PP Convex Head Push-button Mechanical Valve S3PP08R
Genuine AirTAC mechanical valve, order code S3PP08R from the S3 range. The options this code selects are decoded below; series data follow the official AirTAC catalog.
- HeadExtended push button (PP)
- Port1/4" (08)
- Color and threadRed · PT thread
- Function3/2-way
- ActuationExternal control, direct acting
- PortsM5 · PT1/8 · PT1/4
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac S3PP Convex Head Push-button Mechanical Valve S3PP08R
Built on an aluminum-alloy body, the AirTAC S3PP08R is a 3/2-way mechanical valve with PT1/4 ports and the extended push button head (PP) in red. It is worked by hand, as a simple control for an air circuit at the machine or on a panel. At the PT1/4 port the effective area is 12.0 mm2 (Cv 0.67). The catalog gives a spool travel of 2.4-4.0 mm and a head travel of 3.8-5.4 mm.
It is a poppet valve, so it seals tightly and switches cleanly. It runs on air filtered to 40 um from 0 to 1.0 MPa (0-145 psi), with 1.5 MPa (215 psi) proof pressure, at -20 to +70 C. No lubrication is needed; once the valve has been lubricated, keep lubricating it with ISO VG32 oil. The ports are PT thread, the standard version.
Airtac S3PP Convex Head Push-button Mechanical Valve S3PP08R Technical Specifications
| Order code | S3PP08R |
|---|---|
| Product | Mechanical Valve |
| Head | Extended push button (PP) |
| Port | 1/4" (08) |
| Color and thread | Red · PT thread |
| Function | 3/2-way |
|---|---|
| Actuation | External control, direct acting |
| Ports | M5 · PT1/8 · PT1/4 |
| Effective area | M5 2.5 mm² (Cv 0.14) · 1/8" 8.0 mm² (Cv 0.45) · 1/4" 12.0 mm² (Cv 0.67) |
| Travel S3B | spool 2.4–4.0 mm |
| Travel S3C | spool 2.4–3.8 mm · head 14.4–18.4 mm |
| Travel S3D | spool 2.4–3.8 mm · head 7.4–9.4 mm |
| Travel S3V | spool 2.4–3.4 mm · head 3.4–4.8 mm |
| Travel S3R | spool 2.4–3.4 mm · head 5.5–7.8 mm |
| Travel S3L | spool 2.4–3.4 mm · head 6.0–8.6 mm |
| Travel S3PM | spool 2.4–4.0 mm · head 3.8–5.4 mm |
| Travel S3PP | spool 2.4–4.0 mm · head 3.8–5.4 mm |
| Travel S3PF | spool 2.4–4.0 mm · head 3.8–5.4 mm |
| Travel S3PL | spool 2.4–4.0 mm · head 5.9–7.5 mm |
| Travel S3HS | spool 2.4–4.0 mm · head 5.1–6.7 mm |
| Fluid | Air (filtered by 40 µm element) |
| Operating pressure | 0 – 1.0 MPa (0 – 145 psi) |
| Proof pressure | 1.5 MPa (215 psi) |
| Temperature | -20 to +70 °C |
| Lubrication | Not required; once lubricated keep lubricating, ISO VG32 |
| Body | Aluminum alloy |
Source: AirTAC Products Catalog 2026A (PDF01-P0147), S3 series specifications, travel and ordering code.
How to choose
This code uses the 1/4 port (12.0 mm2, Cv 0.67); the same PP head also comes with M5 (Cv 0.14) and 1/8 (06, Cv 0.45). A larger port passes more air when the valve drives a cylinder or a long pilot line directly. The color letter after the port is R (red) here; S3PP08G green and S3PP08B black are the other colors of this head. For BSPP or NPT threads order S3PP08RG or S3PP08RT. Other hand-operated heads: long handle (C), short handle (D), rocker lever (Y), mushroom push button (PM), flush push button (PF), turn-release latching button (PL) and selector switch (HS).
Applications
Start button on a panel
A push button starts an air cycle at the operator panel.
Air-only control desks
Air buttons work where electric switches are not wanted, with no wiring in the panel. The PT1/4 port gives Cv 0.67.
Two-hand and sequence circuits
Sends a pilot signal into an air logic circuit when pressed.
FAQ
What are the key figures of the S3PP08R?
3/2-way mechanical valve, extended push button head (PP), red; PT1/4 ports, effective area 12.0 mm2 (Cv 0.67); 0 to 1.0 MPa (0-145 psi), proof 1.5 MPa (215 psi); -20 to +70 C; air filtered to 40 um; aluminum-alloy body; spool travel 2.4-4.0 mm.
What does the R in S3PP08R mean?
It is the color letter of the extended push button: R = red. Only the push-button and selector heads take a color letter (R red, G green, B black).
