Airtac SAI160 Standard Cylinder SAI160AX100
The AirTAC SAI160 Standard Cylinder SAI160AX100 is a genuine double-acting ISO 15552 profile-barrel air cylinder with a Ø160mm bore and 100mm stroke, G3/4 air ports and adjustable end cushioning. Its standardized mounting interface makes it interchangeable with other ISO 15552 cylinders at the mounting interface.
- BoreØ160 mm
- Stroke100 mm
- Port sizeG3/4
- Acting typeDouble acting
- Rod threadM36×2
- CushionAdjustable, 50 mm
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac SAI160 Standard Cylinder SAI160AX100
The AirTAC SAI160X100 is a robust double-acting profile cylinder engineered to the ISO 15552 standard, offering a direct mounting interface for heavy-duty automation. Operating at 0.7 MPa, it generates a substantial push force of 14074 N, making it well-suited for high-mass displacement tasks over its 100 mm stroke.
This configuration features a SUS420J2 stainless steel piston rod (material code A) for enhanced corrosion resistance in demanding environments. Fluid is supplied via PT tapered ports, and while this unit lacks a magnet, the extruded aluminum barrel includes dual sensor grooves ready for CMSE or DMSE switches if position feedback is later required.
Airtac SAI160 Standard Cylinder SAI160AX100 Technical Specifications
| Model | Airtac SAI160 Standard Cylinder SAI160AX100 |
|---|---|
| Series | SAI ISO 15552 profile cylinder |
| Bore size | Ø160 mm |
| Stroke | 100 mm |
| Acting type | Double acting |
| Port size | G3/4 |
| Rod thread | M36×2 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Adjustable, 50 mm |
| Max stroke | Up to 1500 mm |
Specifications follow the official AirTAC SAI series datasheet and ISO 15552 dimensions. Confirm against the product label before installation. Port options: G (BSPP) / NPT.
Theoretical Output Force (Ø160mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 10053 N | 9425 N |
| 0.7 MPa | 14074 N | — |
| Max (@1.0 MPa) | 2050 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SAI160 Standard Cylinder SAI160AX100
| SAI | ISO 15552 profile-barrel cylinder series. |
|---|---|
| 160 | Bore size in mm. |
| ×100 | Stroke length in mm. |
| -S | Optional built-in magnet for sensor position sensing. |
Related SAI-family variants: SAID (double rod), SAIJ (adjustable stroke), SAIL (with lock), SAIF (with valve), BSAI (enclasp / clamp-lock), and SAI-S with built-in magnet. Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B); seals: TPU (blank) / Viton H / NBR N.
Where the Airtac SAI160 Standard Cylinder SAI160AX100 Is Used
Heavy Stamping
Provides the immense clamping thrust required to hold large metal plates securely during heavy industrial stamping operations.
Injection Molding
Handles the rugged extraction of large molded components from heavy-duty injection molding machinery.
Press Ejection
Delivers reliable, high-force ejection of finished parts from large-scale hydraulic and pneumatic presses.
Is the Airtac SAI160 Standard Cylinder SAI160AX100 the Right Cylinder?
Selecting this 160 mm bore provides immense thrust; stepping down to the 125 mm bore yields 8590 N at 0.7 MPa, whereas the larger 200 mm bore offers 21991 N. For applications requiring the cylinder to maintain a load position without constant air pressure, a standard SAI will drift, so you must specify the SAIL variant with an air-released lock or the BSAI bidirectional clamp-lock.
Ensure your system matches the 160 mm bore specifications: a 100 mm stroke, PT G3/4 port threads, and an M36x2 rod thread. Because this specific build uses a SUS420J2 rod, it is ideal for environments where standard carbon steel might pit or degrade.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/NPT/G)
- ✓ Magnet (-S) for sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (FA/FB/CA/CB/LB/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac SAI160 Standard Cylinder SAI160AX100 FAQ
At an operating pressure of 0.7 MPa, this 160 mm bore cylinder generates a theoretical push force of 14074 N.
Yes, the SAI160X100 is dimensionally interchangeable per ISO 15552, allowing it to serve as a direct replacement for other standard profile cylinders with identical mounting dimensions.
Authorized Export Seller
Genuine AirTAC parts produced by AirTAC factory.
1-Year Warranty
Covers non-human-caused product damage.
Fast Dispatch
Standard models are processed and dispatched in 3-5 business days.
Fast Reply
Most inquiries answered within 7-8 hours.
