Airtac SAI160 Standard Cylinder SAI160AX110S
The AirTAC SAI160 Standard Cylinder SAI160AX110S is a genuine double-acting ISO 15552 profile-barrel air cylinder with a Ø160mm bore and 110mm stroke, G3/4 air ports and adjustable end cushioning. Its standardized mounting interface makes it interchangeable with other ISO 15552 cylinders at the mounting interface.
- BoreØ160 mm
- Stroke110 mm
- Port sizeG3/4
- Acting typeDouble acting
- Rod threadM36×2
- CushionAdjustable, 50 mm
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac SAI160 Standard Cylinder SAI160AX110S
The AirTAC SAI160X110-S is a double-acting ISO 15552 profile cylinder engineered for heavy-duty operations, delivering a substantial push force of 14074 N at 0.7 MPa. This 160 mm bore and 110 mm stroke configuration is tailored for high-impact industrial tasks requiring significant linear thrust over a short, rapid displacement.
Equipped with a SUS420J2 stainless steel rod (material code A) for superior corrosion and wear resistance, this unit also features a built-in magnet (-S) for seamless integration with CMSE or DMSE reed switches along its dual-sided sensor grooves. Fluid connections use PT tapered threads, and the adjustable air cushions at both ends ensure smooth deceleration of large payloads.
Airtac SAI160 Standard Cylinder SAI160AX110S Technical Specifications
| Model | Airtac SAI160 Standard Cylinder SAI160AX110S |
|---|---|
| Series | SAI ISO 15552 profile cylinder |
| Bore size | Ø160 mm |
| Stroke | 110 mm |
| Acting type | Double acting |
| Port size | G3/4 |
| Rod thread | M36×2 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Adjustable, 50 mm |
| Max stroke | Up to 1500 mm |
Specifications follow the official AirTAC SAI series datasheet and ISO 15552 dimensions. Confirm against the product label before installation. Port options: G (BSPP) / NPT.
Theoretical Output Force (Ø160mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 10053 N | 9425 N |
| 0.7 MPa | 14074 N | — |
| Max (@1.0 MPa) | 2050 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SAI160 Standard Cylinder SAI160AX110S
| SAI | ISO 15552 profile-barrel cylinder series. |
|---|---|
| 160 | Bore size in mm. |
| ×110 | Stroke length in mm. |
| -S | Optional built-in magnet for sensor position sensing. |
Related SAI-family variants: SAID (double rod), SAIJ (adjustable stroke), SAIL (with lock), SAIF (with valve), BSAI (enclasp / clamp-lock), and SAI-S with built-in magnet. Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B); seals: TPU (blank) / Viton H / NBR N.
Where the Airtac SAI160 Standard Cylinder SAI160AX110S Is Used
Heavy-Duty Stamping
Provides the intense 14074 N thrust required for metal forming, riveting, and heavy assembly line stamping operations.
Large Mold Clamping
Ideal for securing substantial injection molds or heavy industrial fixtures during high-pressure manufacturing cycles.
Robotic Material Forming
Drives powerful bending or pressing mechanisms in automated cells where a compact 110 mm stroke and massive force are critical.
Is the Airtac SAI160 Standard Cylinder SAI160AX110S the Right Cylinder?
Select this 160 mm bore when a 100 mm bore (5497 N push at 0.7 MPa) cannot generate the necessary clamping or lifting force, but stepping up to a 200 mm bore (21991 N at 0.7 MPa) would be excessive and consume too much compressed air. The 110 mm stroke is optimal for compact, high-force pressing or gripping maneuvers.
Because the stroke is under 300 mm, side-load bending stress on the rod bearing is naturally minimized. However, if the application requires holding a suspended load when air pressure is removed, note that the standard adjustable cushion only decelerates the piston at stroke end and does not act as a brake. For fail-safe position holding, consider the SAIL variant with an air-released lock or an external pilot-operated check valve. To match this cylinder for an ISO 15552 direct replacement, verify the 160 mm bore, 110 mm stroke, G3/4 port, and mounting accessory type.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/NPT/G)
- ✓ Magnet (-S) for sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (FA/FB/CA/CB/LB/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac SAI160 Standard Cylinder SAI160AX110S FAQ
At a 0.7 MPa operating pressure, this 160 mm bore cylinder generates a push force of 14074 N and a pull force of 9425 N. It can reach a theoretical maximum push force of 18095 N at 0.9 MPa.
Yes, the -S suffix indicates this model includes a magnet. It is fully compatible with CMSE or DMSE series sensors, which mount directly into the extruded aluminum barrel's dual sensor grooves.
