Airtac SAI160 Standard Cylinder SAI160AX115
The AirTAC SAI160 Standard Cylinder SAI160AX115 is a genuine double-acting ISO 15552 profile-barrel air cylinder with a Ø160mm bore and 115mm stroke, G3/4 air ports and adjustable end cushioning. Its standardized mounting interface makes it interchangeable with other ISO 15552 cylinders at the mounting interface.
- BoreØ160 mm
- Stroke115 mm
- Port sizeG3/4
- Acting typeDouble acting
- Rod threadM36×2
- CushionAdjustable, 50 mm
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac SAI160 Standard Cylinder SAI160AX115
The AirTAC SAI160X115 is a double-acting ISO 15552 profile cylinder featuring a 160 mm bore and 115 mm stroke. It generates a robust push force of 10053 N at 0.5 MPa, making it well-suited for heavy-duty pressing and lifting tasks. The extruded aluminum barrel design omits tie rods, providing a clean exterior while maintaining strict dimensional interchangeability with other ISO 15552 cylinders.
This specific configuration features a SUS420J2 stainless steel piston rod (material code A) for superior corrosion and wear resistance in demanding environments. It utilizes PT tapered port threads and includes adjustable air cushions at both ends to manage high kinetic energy. Note that this unit lacks a magnet; position sensing requires the -S option to host CMSE or DMSE switches in the dual sensor grooves.
Airtac SAI160 Standard Cylinder SAI160AX115 Technical Specifications
| Model | Airtac SAI160 Standard Cylinder SAI160AX115 |
|---|---|
| Series | SAI ISO 15552 profile cylinder |
| Bore size | Ø160 mm |
| Stroke | 115 mm |
| Acting type | Double acting |
| Port size | G3/4 |
| Rod thread | M36×2 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Adjustable, 50 mm |
| Max stroke | Up to 1500 mm |
Specifications follow the official AirTAC SAI series datasheet and ISO 15552 dimensions. Confirm against the product label before installation. Port options: G (BSPP) / NPT.
Theoretical Output Force (Ø160mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 10053 N | 9425 N |
| 0.7 MPa | 14074 N | — |
| Max (@1.0 MPa) | 2050 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SAI160 Standard Cylinder SAI160AX115
| SAI | ISO 15552 profile-barrel cylinder series. |
|---|---|
| 160 | Bore size in mm. |
| ×115 | Stroke length in mm. |
| -S | Optional built-in magnet for sensor position sensing. |
Related SAI-family variants: SAID (double rod), SAIJ (adjustable stroke), SAIL (with lock), SAIF (with valve), BSAI (enclasp / clamp-lock), and SAI-S with built-in magnet. Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B); seals: TPU (blank) / Viton H / NBR N.
Where the Airtac SAI160 Standard Cylinder SAI160AX115 Is Used
Heavy Duty Stamping
Provides the 10053 N force at 0.5 MPa required to actuate large metal forming and stamping presses reliably.
Automotive Assembly
Drives robust lifting and clamping fixtures on production lines, utilizing the SUS420J2 rod to withstand repetitive stress.
Large Material Handling
Shifts heavy pallets or chassis components, relying on the 160 mm bore's substantial thrust and adjustable cushioning.
Is the Airtac SAI160 Standard Cylinder SAI160AX115 the Right Cylinder?
Select this 160 mm bore when 10053 N of push force at 0.5 MPa is required, stepping up from a 125 mm bore (6136 N) for heavier loads, or down from a 200 mm bore (15708 N) to save space. For applications needing exact end-position holding without live air pressure, a standard SAI will drift; consider the SAIL locking variant or an external rod lock for fail-safe load securement.
Being a genuine AirTAC component, it ensures a precise ISO 15552 mounting interface direct replacement. Match your setup by confirming the 115 mm stroke, PT G3/4 port size, appropriate mounting accessory (like CA clevis or TC trunnion), and adding the -S magnet suffix if sensor tracking is needed.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/NPT/G)
- ✓ Magnet (-S) for sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (FA/FB/CA/CB/LB/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac SAI160 Standard Cylinder SAI160AX115 FAQ
The SAI160X115 cylinder delivers a push force of 10053 N and a pull force of 9425 N at a 0.5 MPa operating pressure.
Yes, the SAI160X115 is a profile cylinder built to strict ISO 15552 dimensional standards, making it a direct replacement for other ISO 15552 cylinders with matching mounting interfaces.
