Airtac SAI50 Standard Cylinder SAI50AX115
The AirTAC SAI50 Standard Cylinder SAI50AX115 is a genuine double-acting ISO 15552 profile-barrel air cylinder with a Ø50mm bore and 115mm stroke, G1/4 air ports and adjustable end cushioning. Its standardized mounting interface makes it interchangeable with other ISO 15552 cylinders at the mounting interface.
- BoreØ50 mm
- Stroke115 mm
- Port sizeG1/4
- Acting typeDouble acting
- Rod threadM16×1.5
- CushionAdjustable, 30 mm
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac SAI50 Standard Cylinder SAI50AX115
The AirTAC SAI50X115 is a double-acting ISO 15552 profile cylinder featuring a 50mm bore and a 115mm stroke. It generates 982N of push force at 0.5 MPa, making it well-suited for medium-duty handling tasks.
This unit incorporates a SUS420J2 stainless steel rod for enhanced corrosion resistance and uses PT tapered port threads. Note that the 115mm stroke is a non-standard made-to-order length, and without a magnet (-S), it cannot host reed sensors like CMSE or DMSE.
Airtac SAI50 Standard Cylinder SAI50AX115 Technical Specifications
| Model | Airtac SAI50 Standard Cylinder SAI50AX115 |
|---|---|
| Series | SAI ISO 15552 profile cylinder |
| Bore size | Ø50 mm |
| Stroke | 115 mm |
| Acting type | Double acting |
| Port size | G1/4 |
| Rod thread | M16×1.5 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 30 mm |
| Max stroke | Up to 1200 mm |
Specifications follow the official AirTAC SAI series datasheet and ISO 15552 dimensions. Confirm against the product label before installation. Port options: G (BSPP) / NPT.
Theoretical Output Force (Ø50mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 982 N | 825 N |
| 0.7 MPa | 1374 N | — |
| Max (@1.0 MPa) | 200 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SAI50 Standard Cylinder SAI50AX115
| SAI | ISO 15552 profile-barrel cylinder series. |
|---|---|
| 50 | Bore size in mm. |
| ×115 | Stroke length in mm. |
| -S | Optional built-in magnet for sensor position sensing. |
Related SAI-family variants: SAID (double rod), SAIJ (adjustable stroke), SAIL (with lock), SAIF (with valve), BSAI (enclasp / clamp-lock), and SAI-S with built-in magnet. Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B); seals: TPU (blank) / Viton H / NBR N.
Where the Airtac SAI50 Standard Cylinder SAI50AX115 Is Used
Component Clamping
Provides reliable 982N clamping force at 0.5 MPa for securing medium-sized metal parts during machining operations.
Product Diverting
Actuates diverting arms on packaging lines to route boxes efficiently without requiring external hydraulics.
Pallet Handling
Pushes or lifts intermediate pallets within automated storage systems, utilizing its robust profile barrel design.
Is the Airtac SAI50 Standard Cylinder SAI50AX115 the Right Cylinder?
If you need less force, stepping down to a 40mm bore yields 628N at 0.5 MPa. For heavier pushing, the 63mm bore offers 1559N at 0.5 MPa. Because this 115mm stroke is a custom length, expect a made-to-order lead time.
This model is dimensionally interchangeable per ISO 15552, serving as a direct replacement for other ISO 15552 profile cylinders. To match this exact configuration, specify a 50mm bore, 115mm stroke, PT port, FA/FB flange mounting, and no magnet. Remember that a standard SAI relies on air pressure to maintain position; if your application must hold a load safely during pressure loss, consider the SAIL variant with an air-released lock.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/NPT/G)
- ✓ Magnet (-S) for sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (FA/FB/CA/CB/LB/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac SAI50 Standard Cylinder SAI50AX115 FAQ
At an operating pressure of 0.5 MPa, the SAI50X115 delivers a push force of 982N and a pull force of 825N.
Yes, the SAI50X115 is a true ISO 15552 profile cylinder, making it dimensionally interchangeable with other ISO 15552 standard cylinders of the same bore size.
