Airtac SAI50 Standard Cylinder SAI50AX135
The AirTAC SAI50 Standard Cylinder SAI50AX135 is a genuine double-acting ISO 15552 profile-barrel air cylinder with a Ø50mm bore and 135mm stroke, G1/4 air ports and adjustable end cushioning. Its standardized mounting interface makes it interchangeable with other ISO 15552 cylinders at the mounting interface.
- BoreØ50 mm
- Stroke135 mm
- Port sizeG1/4
- Acting typeDouble acting
- Rod threadM16×1.5
- CushionAdjustable, 30 mm
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac SAI50 Standard Cylinder SAI50AX135
The AirTAC SAI50X135 is a double-acting ISO 15552 profile cylinder engineered to deliver 982 N of push force at 0.5 MPa. Its 135 mm stroke is a non-standard, made-to-order length, providing exact travel for specialized assembly operations.
This actuator features a SUS420J2 stainless steel piston rod for superior corrosion resistance compared to standard carbon steel. The extruded aluminum barrel includes dual sensor grooves, allowing for flexible mounting of CMSE or DMSE switches if a magnet is added later.
Airtac SAI50 Standard Cylinder SAI50AX135 Technical Specifications
| Model | Airtac SAI50 Standard Cylinder SAI50AX135 |
|---|---|
| Series | SAI ISO 15552 profile cylinder |
| Bore size | Ø50 mm |
| Stroke | 135 mm |
| Acting type | Double acting |
| Port size | G1/4 |
| Rod thread | M16×1.5 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 30 mm |
| Max stroke | Up to 1200 mm |
Specifications follow the official AirTAC SAI series datasheet and ISO 15552 dimensions. Confirm against the product label before installation. Port options: G (BSPP) / NPT.
Theoretical Output Force (Ø50mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 982 N | 825 N |
| 0.7 MPa | 1374 N | — |
| Max (@1.0 MPa) | 200 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SAI50 Standard Cylinder SAI50AX135
| SAI | ISO 15552 profile-barrel cylinder series. |
|---|---|
| 50 | Bore size in mm. |
| ×135 | Stroke length in mm. |
| -S | Optional built-in magnet for sensor position sensing. |
Related SAI-family variants: SAID (double rod), SAIJ (adjustable stroke), SAIL (with lock), SAIF (with valve), BSAI (enclasp / clamp-lock), and SAI-S with built-in magnet. Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B); seals: TPU (blank) / Viton H / NBR N.
Where the Airtac SAI50 Standard Cylinder SAI50AX135 Is Used
Custom Assembly Stations
The exact 135 mm stroke is ideal for specialized jigs requiring precise travel without the slack of a longer standard cylinder.
Package Diverting
Provides 982 N of push force at 0.5 MPa, easily handling medium-weight cartons on a sorting line.
Material Forming
The SUS420J2 stainless steel rod offers reliable performance in humid or lightly corrosive industrial environments.
Is the Airtac SAI50 Standard Cylinder SAI50AX135 the Right Cylinder?
If your application requires less thrust, stepping down to the 40 mm bore yields 628 N at 0.5 MPa. For heavier payloads, the 63 mm bore provides 1559 N. Since this 135 mm stroke is custom, expect a slightly longer lead time.
This model uses a PT tapered port thread. Because a standard SAI cylinder relies on air pressure to maintain its position, it will drift if pressure is lost; for fail-safe load holding, consider the SAIL pneumatic lock variant. Being dimensionally interchangeable per ISO 15552, it serves as a direct replacement for other ISO 15552 profile cylinders.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/NPT/G)
- ✓ Magnet (-S) for sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (FA/FB/CA/CB/LB/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac SAI50 Standard Cylinder SAI50AX135 FAQ
At 0.5 MPa, this 50 mm bore cylinder provides 982 N of push force and 825 N of pull force. At 0.7 MPa, the push force increases to 1374 N.
Yes, as a genuine ISO 15552 profile cylinder, its mounting interface is dimensionally interchangeable with other ISO 15552 cylinders, allowing for seamless direct replacement.
