Airtac SI50 Standard Cylinder SI50X1000SFTC
2. Piston features a durable Y-type axial seal with self-compensating function, providing extended service life and low friction resistance
3. Aluminum tube with crisscross reinforcement design and anodized tie rods for enhanced corrosion resistance
4. Adjustable cushioning for smooth operation
5. Multiple configurations available with comprehensive cylinder variants and mounting accessories for flexible system integration
Category: Standard Cylinders | Brand: AirTAC | Series: SI50
AirTAC SI50X1000SFTC Standard Cylinder Specifications
- Model: SI50X1000SFTC
- Bore size: Ø50 mm
- Stroke: 1000 mm
- Operation type: Double-acting
- Working pressure: 0.1–1.0 MPa
- Cushion type: Adjustable air cushion (both ends)
- Mounting style: Front flange mounting (ISO 15552 standard)
- Port size: G1/4 (NPT1/4 optional)
- Piston rod thread: M16×1.5
- Ambient temperature: -20℃ to 80℃
- Seal material: NBR (Nitrile rubber)
- Protection rating: IP65 (wipers included)
- Magnetic sensor: Pre-installed (2-pin M8 connector)
- Weight: 5.8 kg (including mounting accessories)
- Dimensions: 1190mm(L) × 62mm(W) × 62mm(H)
- Rod end type: Female threaded with pivot eye
- Maximum speed: 800 mm/s
- Theoretical thrust: 785N @0.5MPa (push side)
High-precision long-stroke pneumatic cylinder engineered for heavy-duty industrial applications. Features corrosion-resistant aluminum alloy construction with hard chrome-plated piston rod (20μm thickness). Includes built-in magnet for position feedback and triple-lip wipers for contamination prevention. Requires ISO VG32 hydraulic oil mist lubrication for optimal performance.
- Automated palletizing systems
- Injection molding machine ejectors
- Steel mill rolling equipment
- Automotive assembly line positioning
- Paper processing machinery
- Foundry material handling systems
Installation guidelines:
Ensure proper alignment using precision levels (tolerance ≤0.2mm/m).
For horizontal mounting, support rod end with guided rail system.
Lubricate through air line using 1-2 drops oil per cycle.
Maximum side load: 30N at full extension.
| Property | Property Value |
|---|---|
| sku | SI50X1000SFTC |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT1/4 |
| Piston Rod Material | Medium Carbon Steel |
| Magnet | S-Magnetic |
| Bore Diameter | <50mm> |
| Stroke | <1000mm> |
