This model is discontinued
AirTAC has phased out the SI series. You can still order this code here: we ship the direct replacement SAI80X100, with the same bore, stroke, output force, port and mounting, so it fits the same application. The SAI replacement keeps the same ISO 15552 mounting interface, bore, stroke, output force and accessories, so it drops straight into existing fixtures. It is the current-production version of this cylinder with an upgraded piston seal.
Airtac SI80 Standard Air Cylinder SI80X100
The AirTAC SI80 Standard Air Cylinder SI80X100 is a double-acting ISO 15552 (orig. ISO 6431) profile-barrel cylinder with a Ø80mm bore and 100mm stroke, G3/8 air ports and adjustable end cushioning. This model is discontinued — the direct replacement is the SAI80X100, which matches its ISO interface, bore, stroke, force and mounting.
- BoreØ80 mm
- Stroke100 mm
- Port sizeG3/8
- Acting typeDouble acting
- Rod threadM20×1.5
- StatusDiscontinued → SAI80X100
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac SI80 Standard Air Cylinder SI80X100
The AirTAC SI80X100 is a discontinued double-acting ISO 15552 profile cylinder featuring an extruded aluminum barrel and adjustable air cushions at both ends. Delivering 2513 N of push force at 0.5 MPa, it is replaced by the direct replacement SAI80X100, which maintains the exact same 80 mm bore, 100 mm stroke, G3/8 port, and ISO 15552 mounting interface.
The SAI upgrade introduces a two Y-shaped one-way piston seal for lower start-up pressure and longer life. Note this specific SKU lacks a magnet (-S) and cannot accept a CS1-B/DS1-B sensor.
Airtac SI80 Standard Air Cylinder SI80X100 Technical Specifications
| Model | Airtac SI80 Standard Air Cylinder SI80X100 |
|---|---|
| Series | SI ISO 15552 profile cylinder (discontinued) |
| Replacement | SAI80X100 |
| Bore size | Ø80 mm |
| Stroke | 100 mm |
| Acting type | Double acting |
| Port size | G3/8 |
| Rod thread | M20×1.5 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 36 mm |
| Max standard stroke | Up to 1500 mm |
Specifications follow the official AirTAC SI datasheet (now discontinued). The SAI80X100 carries the same ISO 15552 ratings. Confirm against the product label before installation. Thread options: PT / G / NPT.
Theoretical Output Force (Ø80mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 2513 N | 2268 N |
| 0.7 MPa | 3519 N | — |
| Max (@1.0 MPa) | 513 kgf | |
The SAI80X100 produces the same force from the same bore. Actual usable force is lower than theoretical; size with a margin.
Model Code: Airtac SI80 Standard Air Cylinder SI80X100
| SI | ISO 15552 profile-barrel cylinder (discontinued). |
|---|---|
| 80 | Bore size in mm. |
| ×100 | Stroke length in mm. |
| -S | Optional built-in magnet for sensor position sensing. |
Legacy SI-family variants: SID (double rod), SIJ (adjustable stroke) — each maps to its SAI equivalent (SID→SAID, SIJ→SAIJ). Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B).
Where the Airtac SI80 Standard Air Cylinder SI80X100 Is Used
Press Ejection
Provides the robust 2513 N output needed to reliably eject formed metal parts from heavy stamping dies.
Pallet Diverting
Actuates heavy-duty routing gates on packaging lines, moving loaded pallets with a 100 mm stroke.
Lift Gate Actuation
Drives vertical lifting platforms for material transfer, safely handling loads up to 128 kg.
Replacing the Airtac SI80 Standard Air Cylinder SI80X100 with the SAI80X100
To replace the SI80X100, order the SAI80X100 and verify your ISO 15552 mounting fixtures, G3/8 port threads (PT/G/NPT), and M20x1.5 rod-end connections. This non-magnetic SKU cannot support position sensing, so if switches are needed you must select an SAI80X100S and use current AirTAC switches. Sizing both ways: dropping to a 63 mm bore yields 1559 N push at 0.5 MPa, while stepping up to 100 mm provides 3927 N. A plain cylinder drifts on air loss—the cushion only decelerates—so for load holding consider an external pilot check valve or the SAIL/BSAI lock variants. The 25 mm rod handles the 100 mm stroke easily without side-load concerns.
Replacement checklist
- ✓ Same ISO 15552 interface → SAI80X100
- ✓ Same bore / stroke / force
- ✓ Port/thread type (PT/G/NPT)
- ✓ Magnet (-S) for sensors?
- ✓ Mounting reused (FA/FB/CA/CB/CR/LB/TC)
Airtac SI80 Standard Air Cylinder SI80X100 FAQ
Yes, the SI80X100 is discontinued. The direct replacement is the AirTAC SAI80X100, which shares the identical ISO 15552 mounting interface, 80 mm bore, 100 mm stroke, output force, and G3/8 port.
The G3/8 port feeds a 25 mm piston rod. Force output is 2513 N push and 2268 N pull at 0.5 MPa, 3518 N push at 0.7 MPa, 4523 N push at 0.9 MPa, and a theoretical maximum of 513 kgf at 1.0 MPa. Operating speed is 30-800 mm/s.
