This model is discontinued
AirTAC has phased out the SI series. You can still order this code here: we ship the direct replacement SAI80X100H, with the same bore, stroke, output force, port and mounting, so it fits the same application. The SAI replacement keeps the same ISO 15552 mounting interface, bore, stroke, output force and accessories, so it drops straight into existing fixtures. It is the current-production version of this cylinder with an upgraded piston seal.
Airtac SI80 Standard Air Cylinder SI80X100H
The AirTAC SI80 Standard Air Cylinder SI80X100H is a double-acting ISO 15552 (orig. ISO 6431) profile-barrel cylinder with a Ø80mm bore and 100mm stroke, G3/8 air ports and adjustable end cushioning. This model is discontinued — the direct replacement is the SAI80X100H, which matches its ISO interface, bore, stroke, force and mounting.
- BoreØ80 mm
- Stroke100 mm
- Port sizeG3/8
- Acting typeDouble acting
- Rod threadM20×1.5
- StatusDiscontinued → SAI80X100H
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac SI80 Standard Air Cylinder SI80X100H
The AirTAC SI80X100H is a discontinued double-acting ISO 15552 profile cylinder featuring an extruded aluminum barrel and a Viton H high-temperature seal rated for 0 to 150 C. Delivering 2513 N push force at 0.5 MPa through a G3/8 port, it is replaced by the SAI80X100H.
The SAI direct retains the exact 80 mm bore, 100 mm stroke, M20x1.5 rod thread, and mounting interface. It upgrades the piston seal to two Y-shaped one-way elements for low start-up pressure.
Airtac SI80 Standard Air Cylinder SI80X100H Technical Specifications
| Model | Airtac SI80 Standard Air Cylinder SI80X100H |
|---|---|
| Series | SI ISO 15552 profile cylinder (discontinued) |
| Replacement | SAI80X100H |
| Bore size | Ø80 mm |
| Stroke | 100 mm |
| Acting type | Double acting |
| Port size | G3/8 |
| Rod thread | M20×1.5 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 36 mm |
| Max standard stroke | Up to 1500 mm |
Specifications follow the official AirTAC SI datasheet (now discontinued). The SAI80X100H carries the same ISO 15552 ratings. Confirm against the product label before installation. Thread options: PT / G / NPT.
Theoretical Output Force (Ø80mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 2513 N | 2268 N |
| 0.7 MPa | 3519 N | — |
| Max (@1.0 MPa) | 513 kgf | |
The SAI80X100H produces the same force from the same bore. Actual usable force is lower than theoretical; size with a margin.
Model Code: Airtac SI80 Standard Air Cylinder SI80X100H
| SI | ISO 15552 profile-barrel cylinder (discontinued). |
|---|---|
| 80 | Bore size in mm. |
| ×100 | Stroke length in mm. |
| -S | Optional built-in magnet for sensor position sensing. |
Legacy SI-family variants: SID (double rod), SIJ (adjustable stroke) — each maps to its SAI equivalent (SID→SAID, SIJ→SAIJ). Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B).
Where the Airtac SI80 Standard Air Cylinder SI80X100H Is Used
High-Tactile Pressing
Applies 2513 N at 0.5 MPa for seating bearings or forming light gauge materials where the Viton H seal survives sustained 150 C ambient heat.
Hot Diverters
Drives diverter arms on warm conveyors; the 100 mm stroke shifts packages rapidly while the G3/8 port maintains adequate flow.
Replacing the Airtac SI80 Standard Air Cylinder SI80X100H with the SAI80X100H
To replace the SI80X100H, order the SAI80X100H confirming the ISO 15552 interface, 80 mm bore, 100 mm stroke, G3/8 port, and Viton H seal. For sizing, a 63 mm bore yields 1559 N push at 0.5 MPa, while a 100 mm bore yields 3927 N. This plain cylinder drifts on air loss as the cushion only decelerates; for load holding use the SAIL lock, BSAI clamp-lock, or an external pilot check valve. Since this SKU lacks a magnet, no sensor can be fitted.
Replacement checklist
- ✓ Same ISO 15552 interface → SAI80X100H
- ✓ Same bore / stroke / force
- ✓ Port/thread type (PT/G/NPT)
- ✓ Magnet (-S) for sensors?
- ✓ Mounting reused (FA/FB/CA/CB/CR/LB/TC)
Airtac SI80 Standard Air Cylinder SI80X100H FAQ
Yes, the SI80X100H is discontinued. The direct replacement is the SAI80X100H. It shares the same ISO 15552 mounting interface, 80 mm bore, 100 mm stroke, output force, G3/8 port, and Viton H seal, fitting existing fixtures perfectly.
This 80 mm bore cylinder features a G3/8 port and M20x1.5 rod thread. It delivers 2513 N push and 2268 N pull at 0.5 MPa, 3518 N push at 0.7 MPa, 4523 N push at 0.9 MPa, and a maximum theoretical force of 513 kgf at 1.0 MPa.
