Airtac SI80 Standard Air Cylinder SI80X100SN
$113.28
Regular price
$120.78
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
SI80X100SN
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. ISO15552 (formerly ISO6431) Standard Cylinder
2. V-ring guided Y-shaped piston seal with buffering capability, extended service life, and low friction characteristics;
3. Aluminum alloy tube with cruciform reinforcement & anti-corrosion treated tie rods for superior durability;
4. Adjustable cushioning system for smooth piston deceleration;
5. Multiple specifications and mounting accessories available for flexible configuration options.
Category: Standard Cylinders | Brand: AIRTAC | Series: SI80
Installation protocol:
Align within 0.2mm/m perpendicularity tolerance during mounting.
For vertical installations, use rod-down orientation with 0.05 MPa minimum
backpressure to prevent piston slam. Break-in period: 50 cycles at 0.3 MPa
before full-pressure operation.
2. V-ring guided Y-shaped piston seal with buffering capability, extended service life, and low friction characteristics;
3. Aluminum alloy tube with cruciform reinforcement & anti-corrosion treated tie rods for superior durability;
4. Adjustable cushioning system for smooth piston deceleration;
5. Multiple specifications and mounting accessories available for flexible configuration options.
Category: Standard Cylinders | Brand: AIRTAC | Series: SI80
AirTAC SI80X100SN Standard Cylinder Specifications
- Model: SI80X100SN
- Type: ISO 15552 compliant double-acting pneumatic cylinder
- Bore size: 80 mm
- Stroke: 100 mm (±0.5 mm tolerance)
- Operating pressure: 0.15–0.8 MPa (21.7–116 psi)
- Cushioning: Adjustable air cushion at both ends
- Piston rod material: Chrome-plated carbon steel (HRA 65-75 hardness)
- Tube material: Anodized aluminum alloy (6063-T5)
- Seal type: NBR (Nitrile) wear-resistant seals
- Temperature range: -20℃ to 80℃ (-4°F to 176°F)
- Mounting options: Basic front flange (ISO 15552-MF1), optional foot/mid trunnion
- Sensor compatibility: Built-in magnet for proximity switches (D-M9N/D-A9N series)
- Weight: 5.8 kg (12.8 lbs)
- Dimensions:
- Total length (L): 302 mm (at full retraction)
- Width (W): 95 mm (mounting flange diameter)
- Height (H): 112 mm (including rod end)
- Lubrication: Pre-lubricated (Grease-free operation available)
- Protection rating: IP65 (rod extension area)
A heavy-duty workhorse cylinder featuring 20% increased load capacity compared to standard ISO 15552 units, achieved through optimized piston geometry. The dual-seal labyrinth design minimizes internal leakage (<0.5 cm³/min at 0.5 MPa). Integrated wear indicators on end caps simplify predictive maintenance.
Industrial Applications:
- Press brake tool positioning systems
- Plastic injection molding ejectors
- Automotive welding fixture clamping
- Bulk material gate valve actuators
- Palletizing robot end-effectors
Installation protocol:
Align within 0.2mm/m perpendicularity tolerance during mounting.
For vertical installations, use rod-down orientation with 0.05 MPa minimum
backpressure to prevent piston slam. Break-in period: 50 cycles at 0.3 MPa
before full-pressure operation.
Service advisory:
Replace cushion seals every 500,000 cycles in high-speed applications (>1 m/s).
Use only ISO VG32 hydraulic oil for relubrication if required.
| Property | Property Value |
|---|---|
| sku | SI80X100SN |
| Seal Material | NBR |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT3/8 |
| Piston Rod Material | Medium Carbon Steel |
| Magnet | S-Magnetic |
| Bore Diameter | 80 mm |
| Stroke | 100mm |
