Airtac SU32~50 Standard Cylinder SU32X1100S
2. Features proprietary asymmetric bidirectional piston seal configuration with integrated oil reservoir for compact dimensions;
3. Rodless design with corrosion-resistant octagonal aluminum tube profile (T-slot structure);
4. Superior stroke length compactness compared to ISO 15552 standard cylinders of equivalent bore sizes;
5. Integrated adjustable cushioning mechanism ensures smooth transition at stroke ends;
6. Full compatibility with SC series cylinder mounting accessories;
7. Optional high-temperature seals enable reliable operation at 150°C ambient conditions.
Category: Standard Cylinders | Brand: AirTAC | Series: SU32~50
AirTAC SU32X1100S Standard Cylinder Technical Details
- Series: SU32~50 Standard Series
- Model: SU32X1100S
- Bore size: 32mm
- Stroke: 1100mm
- Action type: Double-acting
- Operating pressure: 0.1-1.0 MPa
- Piston speed: 50-1000mm/s
- Cushioning type: Adjustable rubber buffer (both ends)
- Mounting style: Basic type (MF1) with optional foot/mounting flange
- Rod material: Chrome-plated carbon steel (SCR420)
- Tube material: Aluminum alloy (hard anodized)
- Seal material: NBR (Nitrile Butadiene Rubber)
- Temperature range: -20℃ to 80℃
- Port size: G1/8 (Rc1/8 optional)
- Weight: 5.8kg ±3%
- Dimensions: 1350mm(L) × 50mm(W) × 50mm(H)
- Rod thread: M12×1.25
- Protection class: IP65 (dust-tight & water jet resistant)
- Optional accessories: Magnetic piston (for sensor attachment), auto switch kits
High-precision industrial cylinder optimized for long-stroke applications requiring exceptional straight-line accuracy. Features wear-resistant chromium plating on piston rod and multi-layered sealing system. The aluminum alloy construction ensures lightweight performance while maintaining structural rigidity. Includes 5-position adjustable cushioning mechanism to prevent end-impact damage.
- Automated assembly line material handling
- Packaging machinery pusher mechanisms
- Textile machine tension control systems
- Automotive welding fixture positioning
- Plastic injection molding ejectors
Installation guidance:
For strokes exceeding 500mm, recommend using intermediate support brackets.
Lubricate rod weekly with ISO VG32 hydraulic oil. Avoid side-load forces exceeding
15% of maximum thrust capacity.
- Maximum thrust: 245N at 0.63MPa
- Repeat positioning accuracy: ±0.5mm
- Minimum start pressure: 0.05MPa
- Lifespan: 5,000km travel distance (under standard conditions)
| Property | Property Value |
|---|---|
| sku | SU32X1100S |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Bore Diameter | <32 mm> |
| Stroke | 1100mm |
