Airtac SUJ Adjustable Cylinder SUJ100X100-50S
2. Features specially profiled bidirectional piston sealing structure with compact dimensions and integrated oil reservoir design;
3. Constructed with reinforced octagonal aluminum tubing, rodless configuration demonstrating enhanced corrosion resistance;
4. Maintains more compact length compared to ISO 15552 standard cylinders at equivalent bore sizes;
5. Incorporates adjustable cushioning mechanism for smooth stroke termination;
6. Mounting accessories fully compatible with SC series cylinder components;
7. Utilizes high-temperature resistant seals ensuring reliable operation at 150°C ambient conditions.
Category: Standard Cylinders, Brand: AIRTAC, Series: SUJ
AirTAC SUJ100X100-50S Adjustable Stroke Cylinder Technical Details
- Model: SUJ100X100-50S
- Bore size: 100mm
- Stroke: 100mm (adjustable)
- Max. stroke adjustment range: ±5mm (precise positioning)
- Operating pressure: 0.05-1.0 MPa
- Piston speed: 50-750 mm/s
- Cushioning type: Adjustable air cushion
- Mounting style: Basic type (MF1) with front flange
- Port size: G1/2 (BSPP)
- Ambient temperature: -10℃ to 80℃
- Material: Aluminum alloy barrel, chrome-plated piston rod
- Weight: 6.8kg (with standard accessories)
- Dimensions (L×W×H):
- Retracted length: 318mm
- Extended length: 418mm
- Body width: 120mm
- Mounting height: 145mm
- Lubrication: Pre-lubricated (Oil-free operation possible)
- ISO standard: Compliant with ISO 6432
Heavy-duty adjustable stroke cylinder featuring dual-side stroke adjustment screws for precise end position calibration. The double-sealed structure ensures leak-proof operation in high-cycle applications. Integrated magnet slot enables position sensing compatibility. Anti-rotation design maintains orientation during stroke adjustment.
- Variable height positioning in automotive assembly jigs
- Pressure control systems for plastic injection molding
- Adjustable clamping mechanisms in CNC machining centers
- Material handling systems requiring variable stroke
- Packaging line product height compensators
Adjustment procedure:
Always depressurize before rotating adjustment screws. Use lock nuts after positioning.
Maximum adjustment torque: 1.5N·m. Regular lubrication (ISO VG32) recommended every 500km of cumulative travel.
| Property | Property Value |
|---|---|
| sku | SUJ100X100-50S |
| Adjustable Stroke | <50mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT 1/2 |
| Magnet | S-Magnetic |
| Bore Diameter | 100mm |
| Stroke | 100mm |
