Airtac 200M Solenoid Valve Base 200M-11F
Genuine AirTAC valve manifold, order code 200M-11F from the 4AM range. The options this code selects are decoded below; series data follow the official AirTAC catalog.
- Manifold200M (for 4A200)
- Stations11 stations
- ThreadPT
- Models100M / 200M / 300M / 400M
- For valves4A100 / 4A200 / 4A300 / 4A400
- Maximum stations16 / 16 / 12 / 8
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac 200M Solenoid Valve Base 200M-11F
An 11-station AirTAC 200M base turns eleven 4A200 air-piloted valves into a single bank that shares one supply and one exhaust, so air lines shrink to a single PT connection and troubleshooting follows one common path. With a 1/4 inch supply port P and a calculated length A of 274 mm (44 mm for the first station plus 23 mm for each added one), it suits control cabinets where a dozen stations would be more than the machine needs.
Because 200M banks accept up to 16 stations, this 11F build leaves headroom for later additions; blank stations are sealed with the separate P-200M-R2 plate kit. AirTAC includes the manifold, seals and screws. Feed it air filtered to 40 um and keep the ambient between -20 and +70 C.
Airtac 200M Solenoid Valve Base 200M-11F Technical Specifications
| Order code | 200M-11F |
|---|---|
| Product | Valve Manifold |
| Manifold | 200M (for 4A200) |
| Stations | 11 stations |
| Thread | PT |
| Models | 100M / 200M / 300M / 400M |
|---|---|
| For valves | 4A100 / 4A200 / 4A300 / 4A400 |
| Maximum stations | 16 / 16 / 12 / 8 |
| Supply port P | 1/4" / 1/4" / 3/8" / 1/2" |
| Length A | 100M 38 + 19 × (n-1) mm; 200M 44 + 23 × (n-1) mm; 300M 52 + 28 × (n-1) mm; 400M 61 + 35 × (n-1) mm |
| Fluid | Air, filtered to 40 µm |
| Temperature | -20 to +70 °C |
| Included | Manifold, seals and screws |
| Blank plate | Kit P-□00M-R2 (separate) |
Source: AirTAC 4A manifold datasheet (p.124), ordering code, specifications and dimensions.
How to choose
Match the manifold to the valve series: 200M fits 4A200 only, while 100M, 300M and 400M serve the 4A100, 4A300 and 4A400 valves. If eleven stations is one too many, 200M-10F trims 23 mm of length; if the panel may grow, 200M-12F adds one more station. The PT ending is standard; add G or T to the code for G or NPT threads.
Applications
Assembly machine valve bank
Eleven 4A200 valve outputs feeding clamps and grippers across an assembly station, all served by one PT supply and one common exhaust.
Sorting line actuator cluster
Drive eleven cylinders that divert, stop and lift totes in a sorting or warehouse transfer system from one 274 mm long manifold.
Retrofit of scattered valves
Replace a wall of individual 4A200 valves with a single 200M-11F base, keeping the 1/4 inch supply port and reducing pipework to one feed.
FAQ
How many valves does the 200M-11F take and how long is it?
It takes eleven 4A200 valves, one per station, with a 1/4 inch PT supply port P. Length A is 274 mm, from a 44 mm base plus 23 mm for each added station. Seals and screws are included, and unused stations close with the P-200M-R2 blank plate kit.
What operating conditions should the air meet?
The fluid is air filtered to 40 um, and the temperature range is -20 to +70 C. Keeping the supply clean and the ambient within this range protects the included seals and the valves mounted on the bank.
