Airtac 200M Solenoid Valve Base 200M-4F
Genuine AirTAC valve manifold, order code 200M-4F from the 4AM range. The options this code selects are decoded below; series data follow the official AirTAC catalog.
- Manifold200M (for 4A200)
- Stations4 stations
- ThreadPT
- Models100M / 200M / 300M / 400M
- For valves4A100 / 4A200 / 4A300 / 4A400
- Maximum stations16 / 16 / 12 / 8
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac 200M Solenoid Valve Base 200M-4F
With four stations the 200M-4F reaches 113 mm along its length: a 44 mm first-station base plus 23 mm for each extra 4A200 valve. All four valves breathe from a single 1/4 inch supply port P and exhaust through the common gallery, so the bank behaves as one unit during commissioning and fault finding.
The PT thread is confirmed by the absence of a G or T suffix on the order code. Each order ships with the manifold, seals and screws, while the 4A200 valves are specified separately. Air feeding the bank should be filtered to 40 um and stay within -20 to +70 C.
Airtac 200M Solenoid Valve Base 200M-4F Technical Specifications
| Order code | 200M-4F |
|---|---|
| Product | Valve Manifold |
| Manifold | 200M (for 4A200) |
| Stations | 4 stations |
| Thread | PT |
| Models | 100M / 200M / 300M / 400M |
|---|---|
| For valves | 4A100 / 4A200 / 4A300 / 4A400 |
| Maximum stations | 16 / 16 / 12 / 8 |
| Supply port P | 1/4" / 1/4" / 3/8" / 1/2" |
| Length A | 100M 38 + 19 × (n-1) mm; 200M 44 + 23 × (n-1) mm; 300M 52 + 28 × (n-1) mm; 400M 61 + 35 × (n-1) mm |
| Fluid | Air, filtered to 40 µm |
| Temperature | -20 to +70 °C |
| Included | Manifold, seals and screws |
| Blank plate | Kit P-□00M-R2 (separate) |
Source: AirTAC 4A manifold datasheet (p.124), ordering code, specifications and dimensions.
How to choose
Stay within the 200M family only if your valves are 4A200; the 100M, 300M and 400M manifolds are reserved for 4A100, 4A300 and 4A400 respectively, and the larger two move to 3/8 inch and 1/2 inch supply ports. Against its neighbours, 3F saves 23 mm but leaves nothing spare, while 5F adds a fifth station for another 23 mm of length. Four stations also leaves six free slots if you later jump to a longer code, since 200M accepts up to 16 stations. The thread here is PT.
Applications
Conveyor diverter bank
Pushers and gates at four points along a conveyor each take a 4A200 valve on one 113 mm manifold, fed by a single 1/4 inch air drop.
Clamp-slide-eject-sequence circuits
A small workholder needing clamp, unclamp, slide and eject functions groups all four 4A200 valves on one base for cleaner piping.
Pallet dispensing station
Stack, grip, lift and release cylinders at a pallet dispenser share the 200M-4F bank, so one air supply connection serves the whole station.
FAQ
What are the main figures of the AirTAC 200M-4F?
Four stations for 4A200 valves, supply port P 1/4 inch, PT threads, and length A of 113 mm (44 mm base plus 23 mm per extra station). Operating medium is air filtered to 40 um, temperature range -20 to +70 C.
Can the bank be enlarged later if a fifth valve is needed?
The 200M manifold accepts up to 16 stations, so a longer order code such as 200M-5F covers future growth. Meanwhile, any 200M-4F station left without a valve should be sealed with the separately ordered P-200M-R2 blank plate kit.
