Airtac 200M Solenoid Valve Base 200M-6F
2、Integrated configuration with centralized air supply/exhaust ports and wiring channels, simplifying troubleshooting and maintenance;
3、Flexible modular design with expandable configuration, allowing seamless addition or rearrangement of connected directional control valves to meet evolving system requirements;
Category: Solenoid Valve Manifold Bases , Brand: AIRTAC , Series: 200M
AirTAC 200M-6F Valve Manifold Base Technical Specifications
- Model: 200M-6F
- Type: 6-station modular manifold base
- Port configuration: 6×M5 pilot ports + 1×PT1/4 main supply
- Material: Aircraft-grade aluminum alloy (anodized surface)
- Compatible valves: 100/200/300 series solenoid valves
- Max operating pressure: 1.0 MPa
- Temperature resistance: -20℃ to 80℃
- Seal type: Dual-layer NBR+PTFE gasket
- Mounting style: ISO 15407-1 compliant subplate
- Weight: 520g ±5g
- Dimensions: 98mm(L) × 48mm(W) × 42mm(H)
- Surface hardness: HV 120-150
- Port pitch: 18mm center-to-center
High-density modular base with integrated air passageways for centralized pneumatic control systems. Features cross-drilled flow channels (Φ2.5mm) and anti-vibration mounting slots. Includes built-in silencer pockets and optional bleed valve compatibility. Designed for 100,000+ cycle durability with <2% pressure drop at max flow.
- Multi-axis pneumatic actuator synchronization
- Beverage filling line cluster valve control
- Automated textile machinery air circuits
- Semiconductor wafer handling robots
- Plastic injection molding machine manifolds
Installation protocol:
Use torque-controlled tightening (1.2-1.5N·m) with sequence pattern.
Apply thread sealant only on male fittings. Allow 15mm clearance below
for manifold stacking. Pressure test at 1.5× operating PSI before commissioning.
| Property | Property Value |
|---|---|
| sku | 200M-6F |
