Airtac 200M Solenoid Valve Base 200M-7F
Genuine AirTAC valve manifold, order code 200M-7F from the 4AM range. The options this code selects are decoded below; series data follow the official AirTAC catalog.
- Manifold200M (for 4A200)
- Stations7 stations
- ThreadPT
- Models100M / 200M / 300M / 400M
- For valves4A100 / 4A200 / 4A300 / 4A400
- Maximum stations16 / 16 / 12 / 8
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac 200M Solenoid Valve Base 200M-7F
With seven stations, the AirTAC 200M-7F builds a seven-valve island from 4A200 air-piloted valves that share one 1/4 inch supply port P and one exhaust. That single-point piping keeps the pneumatic cabinet tidier and gives maintenance staff one bank to inspect instead of seven individual valve installations.
At seven stations the bank measures 182 mm long (44 mm base plus 23 mm per added station). The blank thread position in the order code means PT; suffix G or T to the code when G or NPT threads are required. Manifold, seals and screws are all part of the delivery.
Airtac 200M Solenoid Valve Base 200M-7F Technical Specifications
| Order code | 200M-7F |
|---|---|
| Product | Valve Manifold |
| Manifold | 200M (for 4A200) |
| Stations | 7 stations |
| Thread | PT |
| Models | 100M / 200M / 300M / 400M |
|---|---|
| For valves | 4A100 / 4A200 / 4A300 / 4A400 |
| Maximum stations | 16 / 16 / 12 / 8 |
| Supply port P | 1/4" / 1/4" / 3/8" / 1/2" |
| Length A | 100M 38 + 19 × (n-1) mm; 200M 44 + 23 × (n-1) mm; 300M 52 + 28 × (n-1) mm; 400M 61 + 35 × (n-1) mm |
| Fluid | Air, filtered to 40 µm |
| Temperature | -20 to +70 °C |
| Included | Manifold, seals and screws |
| Blank plate | Kit P-□00M-R2 (separate) |
Source: AirTAC 4A manifold datasheet (p.124), ordering code, specifications and dimensions.
How to choose
Step up to 200M-7F from 200M-6F when a seventh 4A200 valve is planned, or down from 200M-8F if eight is too many. The bank can grow to 16 stations, so longer codes such as 200M-9F remain available. For other valve series choose 100M-7F (4A100), 300M-7F (4A300, 3/8 inch supply) or 400M-7F (4A400, 1/2 inch supply, 8-station maximum). Unused stations take the P-200M-R2 blank plate kit.
Applications
Pick-and-place station
Seven 4A200 valves on one 182 mm bank feed the gripper, lift and rotate cylinders of a pick-and-place unit from a single 1/4 inch supply.
Sortation gate cluster
A row of seven diverter gates in a sorting system is driven by one 200M-7F island, so each gate valve shares supply and exhaust piping.
Packaging line stations
Sealing, pressing and ejecting functions along a packaging machine run from one 200M-7F bank, keeping the valve layout aligned with the process steps.
FAQ
What are the key figures of the 200M-7F?
Seven stations for 4A200 valves, supply port P 1/4 inch, PT thread, overall length 182 mm (44 mm plus 23 mm per extra station), air filtered to 40 um, temperature -20 to +70 C. The order includes the manifold, seals and screws.
How do I get NPT or G threads instead of PT on a 200M-7F?
The 200M-7F code with a blank thread position is PT. Add G to the end of the code for G thread or T for NPT. Confirm the exact port detail for your valve set from the datasheet before ordering.
