Airtac 200M Solenoid Valve Base 200M-8F
Genuine AirTAC valve manifold, order code 200M-8F from the 4AM range. The options this code selects are decoded below; series data follow the official AirTAC catalog.
- Manifold200M (for 4A200)
- Stations8 stations
- ThreadPT
- Models100M / 200M / 300M / 400M
- For valves4A100 / 4A200 / 4A300 / 4A400
- Maximum stations16 / 16 / 12 / 8
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac 200M Solenoid Valve Base 200M-8F
The AirTAC 200M-8F groups eight 4A200 air-piloted valves into one valve bank that is fed through a single 1/4 inch supply port P and vents through a shared exhaust. Eight stations is exactly half of the 16-station capacity a 200M manifold can reach, leaving clear room if the machine grows later.
Overall length A at eight stations is 205 mm, from the 44 mm base plus 23 mm per added station. The bank runs on air filtered to 40 um between -20 and +70 C, and the manifold is delivered with its seals and screws. The blank thread position means PT threading.
Airtac 200M Solenoid Valve Base 200M-8F Technical Specifications
| Order code | 200M-8F |
|---|---|
| Product | Valve Manifold |
| Manifold | 200M (for 4A200) |
| Stations | 8 stations |
| Thread | PT |
| Models | 100M / 200M / 300M / 400M |
|---|---|
| For valves | 4A100 / 4A200 / 4A300 / 4A400 |
| Maximum stations | 16 / 16 / 12 / 8 |
| Supply port P | 1/4" / 1/4" / 3/8" / 1/2" |
| Length A | 100M 38 + 19 × (n-1) mm; 200M 44 + 23 × (n-1) mm; 300M 52 + 28 × (n-1) mm; 400M 61 + 35 × (n-1) mm |
| Fluid | Air, filtered to 40 µm |
| Temperature | -20 to +70 °C |
| Included | Manifold, seals and screws |
| Blank plate | Kit P-□00M-R2 (separate) |
Source: AirTAC 4A manifold datasheet (p.124), ordering code, specifications and dimensions.
How to choose
Pick 200M-8F over 200M-7F when an eighth 4A200 valve is needed, and note that longer codes like 200M-9F exist if the bank must expand beyond eight. If your valves are 4A400 rather than 4A200, the equivalent bank is the 400M-8F, which is the maximum size for that series and uses a 1/2 inch supply port. G thread or NPT (T) instead of PT is chosen by ending the order code with G or T. Spare stations are closed with the P-200M-R2 blank plate kit.
Applications
Cabinet-mounted valve island
Eight 4A200 valves arranged on a 205 mm 200M-8F bank give a control cabinet one clean supply connection instead of eight separate ones.
Multi-clamping fixture
Eight clamp cylinders on a welding or machining fixture are switched by the eight stations of one 200M-8F island sharing a 1/4 inch feed.
Standard machine module
An eight-valve module built on 200M-8F repeats identically across machine variants, with PT ports and the same 205 mm footprint every time.
FAQ
What are the key figures of the 200M-8F?
Eight stations for 4A200 valves, supply port P 1/4 inch, PT thread, overall length 205 mm (44 mm plus 23 mm per extra station), air filtered to 40 um, temperature -20 to +70 C, maximum 16 stations on a 200M bank. Supplied with manifold, seals and screws.
How does the 200M-8F differ from the 400M-8F?
Both have eight stations, but 200M-8F is for 4A200 valves with a 1/4 inch supply port and 205 mm length, while 400M-8F is for 4A400 valves with a 1/2 inch supply port and a longer body (61 mm base plus 35 mm per station). Match the manifold code to your valve series.
