Airtac 2WX Fluid Solenoid Valve 2WX05010AI
2. Wide pressure range adaptability with selectable variants: Ultra-high pressure (X), High pressure (H), Standard, High flow (L), and Extra-high flow (T);
3. Compact design with minimal footprint, lightweight construction, and simplified installation/maintenance;
4. Brass valve body with B-class thermal-rated coils. Standard FPMF (Fluorine Rubber) seals ensure multi-media compatibility. Custom seal materials available upon request – consult our technical department;
5. IP65-rated coil protection. Electrical connection options: Direct lead wire or DIN connector.
Category: Fluid Solenoid Valves | Brand: Airtac | Series: 2WX
AirTAC 2WX05010AI Fluid Solenoid Valve Specifications
- Model: 2WX05010AI
- Type: 2-position, 5-port direct-acting solenoid valve
- Port size: G1/8 (ISO228 standard)
- Port configuration: 5/2-way (double solenoid)
- Operating pressure: 0.1–1.0 MPa (14.5–145 PSI)
- Proof pressure: 1.5 MPa
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (±10% 50/60Hz), AC220V (±10% 50/60Hz)
- Coil insulation class: Class F (155℃)
- Weight: 380g ±5% (including coil)
- Dimensions: 58mm(L) × 34mm(W) × 86mm(H)
- Body material: Die-cast aluminum alloy (anodized surface)
- Seal material: Heat-resistant NBR (Nitrile rubber)
- Temperature range: -5℃ to 80℃ (non-freezing)
- Power consumption: 2.8W (DC), 5VA (AC)
- Response time: ≤15ms (exhaust to atmosphere)
- Flow rate: 850 l/min (ANR, at 0.5MPa)
- Protection rating: IP67 (coil), IP40 (valve body)
- Port thread depth: 12mm (minimum engagement)
High-flow proportional control valve with double solenoid operation, featuring rapid response and low power consumption. The aluminum body with corrosion-resistant coating ensures durability in humid environments. Includes manual override function for system debugging and emergency control. Requires filtered compressed air (40μm filter recommended) with lubricator or non-lubricated air supply.
- Automated assembly line cylinder control systems
- Plastic injection molding machine ejectors
- Textile machinery pneumatic circuits
- Food processing equipment actuators
- Semiconductor manufacturing vacuum systems
- Automotive brake testing rigs
Installation guidelines:
Mount horizontally with coil upright. Use flexible tubing near vibration sources.
Allow 15mm clearance around exhaust ports. Perform monthly air filter inspection
in high-cycling applications (>500,000 cycles/month).
