Airtac 300M Solenoid Valve Manifold 300M-11F
2、Centralized air supply/exhaust ports and unified wiring layout simplify troubleshooting during system failures;
3、Modular design with high scalability allows flexible combination and future expansion of connected directional control valves;
Category: Solenoid Valve Base , Brand: AIRTAC , Series: 300M
AirTAC 300M-11F Valve Manifold Base Specifications
- Model: 300M-11F (Modular Base Unit)
- Type: ISO 15407-1 compliant modular manifold base
- Port configuration: 11 stations (1 inlet + 10 outlets)
- Port thread: G1/8 (BSPP) with dual sealing grooves
- Material: Aluminum alloy ADC12 with black anodized finish
- Max operating pressure: 1.0 MPa
- Weight: 620g ±2%
- Dimensions: 198mm(L) × 42mm(W) × 22mm(H)
- Seal material: NBR (Nitrile) with embedded stainless steel backup rings
- Temperature range: -20℃ to 80℃ (continuous operation)
- Surface roughness: Ra ≤3.2μm at sealing interfaces
- Compatible valves: 300 series solenoid valves (300M-08/10/12)
- Mounting pattern: 20mm center-to-center spacing between stations
High-density modular base designed for centralized pneumatic control systems, featuring precision-machined flow channels with turbulence-reducing geometry. The T-slot design enables tool-less valve installation and supports multiple valve configurations. Includes integrated pressure retention chambers and debris-resistant sealing system.
- Multi-axis robotic end effector control
- Beverage filling line manifold systems
- Plastic injection molding machine clusters
- Automated test equipment (ATE) pneumatic routing
- Pharmaceutical blister packaging systems
Installation note:
Apply 0.5-0.7Nm torque during valve mounting. Use thread sealant only on external ports.
Perform air-tightness test at 0.8MPa before full operation. Base alignment tolerance: ±0.15mm/m.
