Airtac 300M Solenoid Valve Manifold 300M-3F
Genuine AirTAC valve manifold, order code 300M-3F from the 4AM range. The options this code selects are decoded below; series data follow the official AirTAC catalog.
- Manifold300M (for 4A300)
- Stations3 stations
- ThreadPT
- Models100M / 200M / 300M / 400M
- For valves4A100 / 4A200 / 4A300 / 4A400
- Maximum stations16 / 16 / 12 / 8
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac 300M Solenoid Valve Manifold 300M-3F
The 300M-3F is the three-station version of the AirTAC 300M manifold, sized for 4A300 air-piloted valves. Its 3/8 inch supply port P feeds all three valves from one point, so you run one air line instead of three and share a common exhaust. With a maximum of 12 stations on the 300M platform, this bank leaves nine positions of expansion headroom while staying compact at 108 mm overall.
Length A for this code is 52 mm for the first station plus 28 mm for each additional one, giving 108 mm across three stations. The PT thread is the catalog default for the 300M ordering code, and the package arrives with the manifold, seals and screws so mounting needs no extra hardware order.
Airtac 300M Solenoid Valve Manifold 300M-3F Technical Specifications
| Order code | 300M-3F |
|---|---|
| Product | Valve Manifold |
| Manifold | 300M (for 4A300) |
| Stations | 3 stations |
| Thread | PT |
| Models | 100M / 200M / 300M / 400M |
|---|---|
| For valves | 4A100 / 4A200 / 4A300 / 4A400 |
| Maximum stations | 16 / 16 / 12 / 8 |
| Supply port P | 1/4" / 1/4" / 3/8" / 1/2" |
| Length A | 100M 38 + 19 × (n-1) mm; 200M 44 + 23 × (n-1) mm; 300M 52 + 28 × (n-1) mm; 400M 61 + 35 × (n-1) mm |
| Fluid | Air, filtered to 40 µm |
| Temperature | -20 to +70 °C |
| Included | Manifold, seals and screws |
| Blank plate | Kit P-□00M-R2 (separate) |
Source: AirTAC 4A manifold datasheet (p.124), ordering code, specifications and dimensions.
How to choose
Pick 300M-3F when the bank holds exactly three 4A300 valves. If you expect to grow toward four or five valves, 300M-4F or 300M-5F give you room now, and any station left open can be closed with the P-300M-R2 blank plate kit ordered separately. For only two valves step down to 300M-2F. PT is standard; if your plant piping is NPT, order the same manifold with a G or T thread suffix. Larger 4A400 valves require the 400M manifold series instead.
Applications
Robot cell valve cluster
Mount three 4A300 valves on one 108 mm bank next to the robot, feeding grippers and clamps from a single 3/8 inch supply instead of three separate lines.
Carton sealing station
Run the flap press, box clamp and ejector cylinders of a sealing head from one shared supply and exhaust, which makes fault tracing on the line faster.
Conveyor diverting point
Group the pusher, stopper and gate valves at a diverter so all three pilot valves share one filtered-air feed at -20 to +70 C ambient.
FAQ
What are the key figures of the 300M-3F?
Manifold 300M for three 4A300 valves, PT thread. Length A is 108 mm (52 mm base plus 28 mm per extra station), supply port P is 3/8 inch, and the 300M series allows up to 12 stations. Fluid is air filtered to 40 um, operating temperature -20 to +70 C. The delivery includes manifold, seals and screws; unused stations take the separate P-300M-R2 blank plate kit.
Can I add a fourth valve to this manifold later?
Yes. The 300M platform accepts up to 12 stations, so a fourth 4A300 valve fits the next position. Order the P-300M-R2 blank plate kit for any station you want to keep closed in the meantime.
