AirTAC 3V200M-10 3V-F Base (3V200M10F)
The AirTAC AirTAC 3V200M-10 3V-F Base (3V200M10F) is a genuine 3V-F manifold base manifold base for 10 stations on one shared air supply. A base is a machined block: it carries no coil and no solenoid, so the valves that sit on it are ordered separately.
- Valve type3/2-way (3-port, 2-position)
- Stations10
- Series3V-F manifold base
About the AirTAC 3V200M-10 3V-F Base (3V200M10F)
The 3V200M10F is the 10-station manifold base for AirTAC 3V2 series 3/2 valves. Each mounted valve keeps the defining 3/2 behaviour - three ports, two states, feeding or venting the outlet - while the base feeds all ten positions from a single air line.
A genuine AirTAC part, ordered as a base with the valves bought separately. The 3V2 family covers both NC and NO states, five coil voltages and both DIN plug and flying-lead entries, and 3V2 valves are among the AirTAC bodies whose flow and coil-power figures are published in their own documentation. We will send those datasheets on request.
AirTAC 3V200M-10 3V-F Base (3V200M10F) Technical Specifications
| Model | AirTAC 3V200M-10 3V-F Base (3V200M10F) |
|---|---|
| Series | 3V-F manifold base |
| Item form | Manifold base (no coil, no solenoid, no initial state) |
| Stations | 10 |
| Port size | Confirm from the datasheet — ask us |
| Thread | PT |
| Operating pressure | Confirm from the datasheet — ask us |
|---|---|
| Flow coefficient | Confirm from the datasheet — ask us |
| Temperature | Confirm from the datasheet — ask us |
| Protection | Confirm from the datasheet — ask us |
Model Code: AirTAC 3V200M-10 3V-F Base (3V200M10F)
| 3V-F manifold base | Body. |
|---|---|
| 10F | 10 stations in one assembly. |
| PT | Port thread. PT ships from stock; G and NPT are available to order. |
What a 3/2 Valve Does
A 3/2 valve has three ports — supply, outlet and exhaust — and two states. It either feeds the outlet or vents it to exhaust, and that is the whole job.
That makes it the right valve for a single-acting (spring-return) cylinder, on/off air blow, a clamp, switching a vacuum generator or suction cup, and piloting a larger valve.
It cannot run a double-acting cylinder. A double-acting cylinder needs air alternately on two sides, which takes a 5-port valve — the AirTAC 4V series.
Where the AirTAC 3V200M-10 3V-F Base (3V200M10F) Is Used
Bottling line valve island
A filling or bottling line grouping ten 3/2 valves for reject pushers, divider gates and short air blasts, all on one supply.
Pilot stage for larger valves
Low-flow pilot signals staged on the manifold to switch larger process and cylinder valves elsewhere in the circuit.
Machine OEM design
An engineering team specifying a 10-station air manifold early in a new machine build, leaving spare stations for options added later.
Is the AirTAC 3V200M-10 3V-F Base (3V200M10F) the Right Part?
Ten stations is a serious bank, so plan it like one: list every actuator at design time, decide NC or NO per station for the fail-safe behaviour you want, and keep one coil voltage across the whole loom unless your control system genuinely splits it. Valves are ordered separately, so the base can be bought first and filled as the machine grows.
A useful advantage here is that the 3V2 valves which fit this base belong to the AirTAC bodies with published flow and coil-power figures - ask us and we will quote those from the datasheet, station by station, to confirm sizing. If any actuator on the list is double-acting, it needs a 5-port AirTAC 4V valve instead of any 3/2.
Confirm before you order
- ✓ Port size and thread (PT from stock; G / NPT to order)
- ✓ Initial state — NC or NO, ordered up front
- ✓ Coil voltage matches your controller output
- ✓ Electrical entry — DIN plug or flying lead
- ✓ Single valve, bare base, or complete assembly
- ✓ Single-acting duty, not double-acting
Installation & Wiring Notes
- check Use clean air filtered to 40µm or finer.
- check Use the manual override to test before powering up.
- check Leave the exhaust port clear, or fit a silencer.
- check Blank any unused station on the base before pressurising.
- check Wiring by qualified personnel, per AirTAC documentation.
AirTAC 3V200M-10 3V-F Base (3V200M10F) FAQ
No. The base itself is pipework, and the 3V2 valves that fill it are specified in their own datasheet - ask us and we will send the pressure, flow and coil-power figures for the exact part numbers you plan to order. Where a fully documented 3-port valve is needed immediately, the 3V2 and 3V3 bodies are the ones with published figures.
No. A 3/2 valve has one outlet, which it either feeds or vents, so it suits single-acting spring-return cylinders, clamps, blow duty and piloting. A double-acting cylinder needs two ports pressurised and exhausted alternately - that is a 5-port job for the AirTAC 4V series.
