Airtac 3V-F Base 3V200M11F
2、Features centralized inlet/exhaust ports and unified wiring configuration, which simplifies troubleshooting during system failures;
3、Offers flexible configuration and high expandability, allowing arbitrary combination or modular expansion of connected directional control valves;
Category: Solenoid Valve Bases | Brand: AIRTAC | Series: 3V-F
AirTAC 3V200M11F Valve Base Specifications
- Model: 3V200M11F (3V-F Series Modular Base)
- Compatibility: Designed for 3V2/3V3 series solenoid valves
- Port configuration: 5-port (P, A, B, R, S)
- Port size: G1/8 (ISO standard)
- Thread type: Metric (M5x0.8 optional)
- Max operating pressure: 1.0 MPa
- Min operating pressure: 0.15 MPa
- Material: Aluminum alloy (anodized surface)
- Seal material: NBR (Nitrile rubber)
- Temperature range: -5℃ to 80℃
- Mounting hole spacing: 80mm × 40mm (horizontal × vertical)
- Weight: 320g ±5g
- Dimensions: 100mm(L) × 50mm(W) × 25mm(H)
- Surface roughness: Ra ≤3.2μm
- Protection rating: IP40 (dust protected)
Modular aluminum base with precision-machined flow channels, engineered for multi-valve stacking in complex pneumatic systems. Features dual-position exhaust ports (R/S) for enhanced flow efficiency and anti-corrosion coating for humid environments. Includes integrated O-ring grooves for leak-proof valve connections.
- Modular pneumatic control stations
- Automated assembly line manifolds
- Packaging machine valve clusters
- Robotic tool changer systems
- CNC machine pneumatic circuits
Installation protocol:
Use M5×25mm hex socket screws (recommended torque 1.2N·m) for valve mounting.
Align manifold grooves with valve body pins before tightening. Apply silicone-free
lubricant to O-rings during assembly.
Maintenance note:
Inspect exhaust silencers quarterly for particle accumulation.
Do not exceed 80℃ continuous operation to prevent seal degradation.
