AirTAC 3V-F manifold base · Manifold Base

AirTAC 3V200M-16 3V-F Base (3V200M16F)

The AirTAC 3V200M-16 3V-F Base (3V200M16F) is a genuine 3V-F manifold base manifold base for 16 stations on one shared air supply. A base is a machined block: it carries no coil and no solenoid, so the valves that sit on it are ordered separately.

  • Valve type3/2-way (3-port, 2-position)
  • Stations16
  • Series3V-F manifold base
$46.16 $50.99Save 9% Standard model — usually dispatched in 3-5 days
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Shipped from our own warehouse: most standard models dispatch in 3–5 days; custom and non-standard models take 8–10 business days. Transit time after that depends on the destination.
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7 h

About the AirTAC 3V200M-16 3V-F Base (3V200M16F)

The 3V200M16F is a machined manifold base for AirTAC 3/2 solenoid valves, drilled for 16 stations. A manifold base sits behind a row of valves and feeds every station from one common air supply, so a sixteen-valve panel needs a single feed line instead of sixteen separate tees and sixteen lengths of tubing. The base itself carries no coil, draws no power and has no switching state - all of that belongs to the valves, which are ordered separately and mounted onto it.

We stock the 3V200M16F as a genuine AirTAC part. To complete a sixteen-station assembly, pair it with 16 of the matching 3V200-body valves in whatever mix of NC and NO states, coil voltages and electrical entries your panel needs - we carry all of those options across the family. If you need datasheet figures for this base or the valves that mount on it, ask us and we will confirm them from the manufacturer documentation before you order.

AirTAC 3V200M-16 3V-F Base (3V200M16F) Technical Specifications

ModelAirTAC 3V200M-16 3V-F Base (3V200M16F)
Series3V-F manifold base
Item formManifold base (no coil, no solenoid, no initial state)
Stations16
Port sizeConfirm from the datasheet — ask us
ThreadPT
Operating pressureConfirm from the datasheet — ask us
Flow coefficientConfirm from the datasheet — ask us
TemperatureConfirm from the datasheet — ask us
ProtectionConfirm from the datasheet — ask us
We do not publish figures we cannot stand behind. We supply this code as a genuine AirTAC part, but we do not hold a specification sheet for the 3V-F manifold base family. Operating pressure, flow, coil power, protection rating and temperature are therefore not printed here — send us the model and we will confirm them from the factory datasheet, usually within 7 hours.

Model Code: AirTAC 3V200M-16 3V-F Base (3V200M16F)

3V-F manifold baseBody.
16F16 stations in one assembly.
PTPort thread. PT is standard; G and NPT are available to order.

What a 3/2 Valve Does

A 3/2 valve has three ports — supply, outlet and exhaust — and two states. It either feeds the outlet or vents it to exhaust, and that is the whole job.

That makes it the right valve for a single-acting (spring-return) cylinder, on/off air blow, a clamp, switching a vacuum generator or suction cup, and piloting a larger valve.

It cannot run a double-acting cylinder. A double-acting cylinder needs air alternately on two sides, which takes a 5-port valve — the AirTAC 4V series.

Where the AirTAC 3V200M-16 3V-F Base (3V200M16F) Is Used

settings_input_component

Packaging machine clamp panel

A cartoning line with a dozen-plus single-acting clamp and pusher cylinders can mount one 3/2 valve per function on this 16-station base, sharing one air feed and one tidy wiring run behind the control panel instead of a nest of individual fittings.

air

Multi-nozzle blow-off station

An assembly cell that clears chips or dries parts at several points can switch each nozzle independently with its own 3/2 valve on this base, giving operators per-station control of on/off air blow from one common supply.

conveyor_belt

Conveyor stopper and divert bank

A sorting conveyor with spring-return stoppers, kickers and gate cylinders at up to sixteen positions can drive every function from one 3V200M16F base, simplifying both the plumbing and fault-finding when one station misbehaves.

Is the AirTAC 3V200M-16 3V-F Base (3V200M16F) the Right Part?

Start with the station count: this is the 16-station member of the 3V200M range, which spans smaller and larger counts, so match the base to the number of 3/2 functions your machine actually needs and leave a spare station or two for later changes. Remember the base is only the block - every valve is a separate line item, and each one's NC or NO state, coil voltage and DIN or flying-lead entry must be chosen to suit your panel. Thread is PT as the manufacturer standard, with G and NPT available as order options. Because published flow figures for this family are not in our hands, send us your actuator sizes and ask us to confirm sizing against them before you commit. If you want a fully specified 3-port valve today, the documented 3V2 and 3V3 direct-acting bodies carry published flow and coil-power figures. And if any of your functions is a double-acting cylinder, that needs a 5-port valve from the AirTAC 4V series, not a 3/2 on this base.

Confirm before you order

  • ✓ Port size and thread (PT standard; G / NPT to order)
  • ✓ Initial state — NC or NO, ordered up front
  • ✓ Coil voltage matches your controller output
  • ✓ Electrical entry — DIN plug or flying lead
  • ✓ Single valve, bare base, or complete assembly
  • ✓ Single-acting duty, not double-acting
Ask an Engineer

Installation & Wiring Notes

  • check Use clean air filtered to 40µm or finer.
  • check Use the manual override to test before powering up.
  • check Leave the exhaust port clear, or fit a silencer.
  • check Blank any unused station on the base before pressurising.
  • check Wiring by qualified personnel, per AirTAC documentation.

AirTAC 3V200M-16 3V-F Base (3V200M16F) FAQ

We do not publish figures for this family, so rather than quote numbers we cannot stand behind, we confirm pressure, flow and dimensional data for this base - and for the valves that mount on it - directly from the AirTAC datasheet on request. Send the RFQ with your station plan and we will return the specifics. If you need published flow and coil-power figures in hand right now, choose the documented 3V2 or 3V3 valve bodies instead, where those figures are available.

No. This is the manifold base only - a machined block with 16 stations and no coil, so it has no voltage, no switching state and no power draw of its own. Each valve is ordered separately, and that is where you pick NC or NO per station: NC valves leave the outlet vented until energised, NO valves feed it until energised. Match each valve's coil voltage to your panel supply, then mount them onto the base for a single shared air feed.
