Airtac 3V-F Base 3V200M18F
2、Features centralized inlet/exhaust ports and unified wiring configuration, which simplifies troubleshooting during system failures;
3、Offers flexible configuration and high expandability, allowing arbitrary combination or modular expansion of connected directional control valves;
Category: Solenoid Valve Bases | Brand: AIRTAC | Series: 3V-F
AirTAC 3V200M18F Base Manifold Technical Specifications
- Model: 3V200M18F (3V-F Series)
- Type: Modular aluminum base manifold
- Port size: PT1/4 (G1/4 equivalent)
- Mounting pattern: ISO 15407-1 compliant
- Thread specification: M18×1.5 mounting holes
- Max operating pressure: 1.0 MPa
- Pressure range: 0.05–1.0 MPa
- Temperature range: -5℃ to 80℃ (with NBR seals)
- Material: Anodized aluminum alloy (AL6063-T5)
- Surface hardness: HV 12±2
- Weight: 380±10g
- Dimensions: 200mm(L) × 18mm(W) × 42mm(H)
- Port spacing: 18mm center-to-center
- Seal compatibility: NBR/FKM/EPDM options
- Chemical resistance: Resists hydraulic oils & mild solvents
High-strength modular base designed for multi-valve stacking in pneumatic systems. Features precision-machined flow channels with optimized pressure drop characteristics (ΔP≤0.02MPa @ 0.5MPa). The anodized surface treatment provides enhanced corrosion resistance for humid environments. Compatible with 3V210/3V310 series valves.
- Centralized valve control in assembly line automation
- Modular pneumatic stations for packaging machinery
- Multi-axis actuator control systems
- Plastic injection molding machine manifolds
- Semiconductor manufacturing equipment
Installation guidelines:
Use M18×1.5 stainless steel fasteners with 18-22 N·m torque.
Apply thread sealant on end plate screws. Maximum recommended
stack height: 5 valves per manifold section. Flush with dry air
before initial operation.
| Property | Property Value |
|---|---|
| sku | 3V200M18F |
