Airtac 3V-F Base 3V200M19F
2、Features centralized inlet/exhaust ports and unified wiring configuration, which simplifies troubleshooting during system failures;
3、Offers flexible configuration and high expandability, allowing arbitrary combination or modular expansion of connected directional control valves;
Category: Solenoid Valve Bases | Brand: AIRTAC | Series: 3V-F
AirTAC 3V200M19F Base Manifold Technical Specifications
- Model: 3V200M19F (3V-F Series Base)
- Port configuration: 2-position manifold base
- Thread standard: G1/8 (ISO228-1) with optional NPT1/8
- Max operating pressure: 1.0 MPa
- Min operating pressure: 0.15 MPa
- Temperature resistance: -5℃ to 80℃
- Material: Reinforced PA66 + 30% glass fiber
- Surface finish: Anti-corrosion anodizing
- Port spacing: 18mm center-to-center
- Weight: 320g ±5g
- Dimensions: 78mm(L) × 34mm(W) × 42mm(H)
- Compatible valves: 3V1/3V2/3V3 series solenoid valves
- Seal compatibility: Compatible with NBR, FKM, and EPDM seals
- Vibration resistance: 10-55Hz, 1.5mm amplitude
Modular base manifold designed for multi-valve centralized control systems, featuring integrated air passages for simplified piping. The staggered port design reduces turbulence and pressure drop by 18% compared to standard manifolds. Includes built-in mounting slots for DIN rail (35mm) or direct panel installation.
- Automated assembly line valve clusters
- Plastic injection molding machine pneumatic circuits
- Multi-axis robotic tool changers
- Semiconductor manufacturing equipment
- Packaging machine sequential control systems
Installation guidelines:
Apply 3-5Nm torque during valve mounting. Use PTFE tape on external threads.
For multi-base stacking, ensure alignment pins engage properly. Flush manifold
with clean dry air (dew point -20℃) before initial operation.
| Property | Property Value |
|---|---|
| sku | 3V200M19F |
