AirTAC 3V-F manifold base · Manifold Base

Airtac 3V-F Base 3V300M3F

The AirTAC 3V-F Base 3V300M3F is a genuine 3V-F manifold base manifold base for 3 stations on one shared air supply. A base is a machined block: it carries no coil and no solenoid, so the valves that sit on it are ordered separately.

  • Valve type3/2-way (3-port, 2-position)
  • Stations3
  • Series3V-F manifold base
$22.75 $27.00Save 15% Standard model — usually dispatched in 3-5 days
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Shipped from our own warehouse: most standard models dispatch in 3–5 days; custom and non-standard models take 8–10 business days. Transit time after that depends on the destination.
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7 h

About the Airtac 3V-F Base 3V300M3F

A 3V300M3F is the three-station member of the AirTAC 3V-F manifold family: one machined block, three valve positions, one common air supply. Each position takes a 3/2 solenoid valve - supply, outlet, exhaust - that either feeds its outlet or vents it, so a single block can run three spring-return cylinders, three blow lines or three pilot signals from one feed. Fewer individual fittings also mean fewer places for a leak or a loose wire to hide.

The base itself has no coil, no voltage and no state - those choices belong to the valves, which are ordered separately. Across the matching 3V1 valves you can choose normally closed or normally open, five coil voltages (AC220V, DC24V, AC110V, AC24V, DC12V) and either a DIN plug or a flying-lead entry. This is a genuine AirTAC part. Datasheet figures for the chosen valves are confirmed by our engineers on request - just list the valve codes on the RFQ.

Airtac 3V-F Base 3V300M3F Technical Specifications

ModelAirtac 3V-F Base 3V300M3F
Series3V-F manifold base
Item formManifold base (no coil, no solenoid, no initial state)
Stations3
Port sizeConfirm from the datasheet — ask us
ThreadPT
Operating pressureConfirm from the datasheet — ask us
Flow coefficientConfirm from the datasheet — ask us
TemperatureConfirm from the datasheet — ask us
ProtectionConfirm from the datasheet — ask us
We do not publish figures we cannot stand behind. We supply this code as a genuine AirTAC part, but we do not hold a specification sheet for the 3V-F manifold base family. Operating pressure, flow, coil power, protection rating and temperature are therefore not printed here — send us the model and we will confirm them from the factory datasheet, usually within 7 hours.

Model Code: Airtac 3V-F Base 3V300M3F

3V-F manifold baseBody.
3F3 stations in one assembly.
PTPort thread. PT is standard; G and NPT are available to order.

What a 3/2 Valve Does

A 3/2 valve has three ports — supply, outlet and exhaust — and two states. It either feeds the outlet or vents it to exhaust, and that is the whole job.

That makes it the right valve for a single-acting (spring-return) cylinder, on/off air blow, a clamp, switching a vacuum generator or suction cup, and piloting a larger valve.

It cannot run a double-acting cylinder. A double-acting cylinder needs air alternately on two sides, which takes a 5-port valve — the AirTAC 4V series.

Where the Airtac 3V-F Base 3V300M3F Is Used

settings_input_component

OEM control panel build

A panel builder mounting three 3/2 valves for clamp, eject and blow functions behind one bulkhead fitting, cutting tubing runs and points of failure.

conveyor_belt

Conveyor stopper and reject station

A sorting line using one valve for a pneumatically raised stopper, one for a pusher reject finger and one for a dust blow-off between them.

science

Laboratory rig air sequencing

A test rig that vents a sample chamber and switches a small suction generator at separate moments, each function on its own valve position.

Is the Airtac 3V-F Base 3V300M3F the Right Part?

Three positions give room for a small machine that does three things with air - clamp, blow and vent, for instance - without three separate valve bodies and three separate supplies. Fit each position with a separately ordered 3V1 valve: NC where the line must vent and the outlet go dead on power loss, NO where it must stay fed; the coil voltage must equal the panel supply and cannot be changed by rewiring. Published flow and coil-power figures for this family are not available to us, so send the actuator details and we will confirm sizing from the datasheet before you order. Buyers who need a 3-port valve with printed figures right now should look at the documented AirTAC 3V2 and 3V3 series. For double-acting cylinders, the 5-port AirTAC 4V range is the correct route.

Confirm before you order

  • ✓ Port size and thread (PT standard; G / NPT to order)
  • ✓ Initial state — NC or NO, ordered up front
  • ✓ Coil voltage matches your controller output
  • ✓ Electrical entry — DIN plug or flying lead
  • ✓ Single valve, bare base, or complete assembly
  • ✓ Single-acting duty, not double-acting
Ask an Engineer

Installation & Wiring Notes

  • check Use clean air filtered to 40µm or finer.
  • check Use the manual override to test before powering up.
  • check Leave the exhaust port clear, or fit a silencer.
  • check Blank any unused station on the base before pressurising.
  • check Wiring by qualified personnel, per AirTAC documentation.

Airtac 3V-F Base 3V300M3F FAQ

Yes - send the RFQ with the valve codes you plan to fit and we will confirm pressure range, flow and coil power from the datasheet. This page carries no performance figures because the 3V1 family data is not published here; the documented AirTAC 3V2 and 3V3 3-port series do publish flow and coil power if you need numbers immediately.

One machined base gives you one air feed, one mounting point and one tidy wiring run, which makes faults quicker to isolate - each valve can still be checked individually. The valves themselves, with their state, voltage and entry, are ordered separately. And keep in mind a 3/2 valve feeds or vents one outlet only; a double-acting cylinder needs a 5-port valve from the AirTAC 4V series.
