Airtac 3V200 Solenoid Valve 3V21006NCA-AM
2. Spool-type structure with excellent sealing properties and high responsiveness;
3. Dual-coil design features memory function (position retention upon power loss);
4. Precision-engineered internal bore reduces friction resistance, enables low activation pressure (0.15MPa) and ensures extended service life;
5. Lubrication-free operation;
6. Integrated manual override for simplified commissioning and maintenance;
7. Multiple standardized voltage options available;
8. Modular valve system compatibility with manifold bases for space-optimized installations.
Category: Solenoid Valves | Brand: AirTAC | Series: 3V200
AirTAC 3V200 Series Solenoid Valve 3V21006NCA-AM Technical Details
- Full model designation: 3V21006NCA-AM (ISO 5599-1 compliant)
- Valve type: 3/2-way normally closed, pilot-operated
- Port thread: PT1/8" (BSPP) with M5 sub-port option
- Effective bore diameter: 2.5mm
- Operating pressure range: 0.15–1.0 MPa (21.7–145 PSI)
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Coil insulation class: Class F (155°C)
- Power consumption: 1.6W (DC), 2.5VA (AC)
- Response time: ≤15ms (energize), ≤20ms (de-energize)
- Flow rate: 750Nl/min (ANR, at 0.5MPa differential)
- Seal material: HNBR (Hydrogenated Nitrile) for improved oil resistance
- Ambient temperature: -20℃ to +80℃ (non-freezing)
- Protection rating: IP67 (dust tight & temporary immersion)
- Weight: 180g ±5g (with DIN connector)
- Dimensions: 52mm(L) × 34mm(W) × 67mm(H) (excluding fittings)
- Port alignment: 25mm center-to-center spacing
- Mounting orientation: Any (recommended vertical for optimal drainage)
High-cycle electromagnetic valve featuring corrosion-resistant anodized aluminum body and manual override capability. The optimized flow path design reduces pressure drop by 18% compared to previous generations. Includes surge protection circuitry and LED operation indicator. Requires ISO 8573-1:2010 Class 3.4.2 compressed air (max 5mg/m³ oil content).
- High-speed textile machinery thread control systems
- Plastic injection molding machine ejector mechanisms
- Semiconductor wafer handling vacuum/pressure switching
- Food processing pneumatic actuators (FDA-compliant grease option available)
- Electric vehicle battery cooling system valves
Installation guidelines:
Use flexible tubing to minimize vibration transfer. For horizontal mounting,
install exhaust port downward. Perform monthly manual cycling if inactive
for extended periods. Minimum 100mm clearance recommended above valve for
maintenance access.
| Property | Property Value |
|---|---|
| sku | 3V21006NCA-AM |
| Position | 3-Port 2-Position |
| Port Size | PT1/8 |
| Standard Voltage | AC220V |
