Airtac 3V200 Solenoid Valve 3V21006NCB-AM
2. Spool-type structure with excellent sealing properties and high responsiveness;
3. Dual-coil design features memory function (position retention upon power loss);
4. Precision-engineered internal bore reduces friction resistance, enables low activation pressure (0.15MPa) and ensures extended service life;
5. Lubrication-free operation;
6. Integrated manual override for simplified commissioning and maintenance;
7. Multiple standardized voltage options available;
8. Modular valve system compatibility with manifold bases for space-optimized installations.
Category: Solenoid Valves | Brand: AirTAC | Series: 3V200
AirTAC 3V200 Series Solenoid Valve 3V21006NCB-AM Technical Details
- Full Model Code: 3V21006NCB-AM (Standard coil with manual override)
- Valve Type: 3/2-way normally closed, pilot-operated
- Port Thread: PT1/8" (BSPP) with M5x0.8 sub-port option
- Effective Sectional Area: 8.0 mm²
- Operating Pressure Range: 0.05–1.0 MPa (0.5–10 bar)
- Voltage Tolerance: ±10% for all variants
- Voltage Options:
- DC: 12V, 24V
- AC: 110V 50/60Hz, 220V 50Hz
- Response Time: ≤15ms (energized), ≤20ms (de-energized)
- Flow Rate: 120 NL/min at 0.5 MPa
- Seal Material: HNBR (Hydrogenated Nitrile) for improved oil resistance
- Ambient Temperature: -5℃ to 80℃ (no freeze)
- Fluid Temperature: 1℃ to 60℃
- Protection Class: IP67 (dust-tight, temporary immersion protection)
- Electrical Connection: DIN43650 Form A with LED indicator
- Housing Material: Glass-filled polyamide (PA66-GF25)
- Weight: 185g ±5g (without connector)
- Dimensions: 53mm(L) × 35mm(W) × 44mm(H) (excluding fittings)
- Service Life: ≥10 million cycles (at rated conditions)
High-cycle solenoid valve with manual override function, featuring optimized flow paths for reduced pressure drop. The reinforced coil design ensures stable operation in high-vibration environments. Requires ISO 8573-1:2010 Class 3 compressed air (max. 5mg/m³ oil content). Includes surge protection circuitry for enhanced durability.
- CNC machine tool clamping systems
- Beverage filling line pneumatic actuators
- Plastic injection molding ejectors
- Automated test equipment sequencing
- Lithium battery production dry rooms
Maintenance Protocol:
Lubricate spool every 6 months with ISO VG32 turbine oil.
For horizontal mounting, install drip-proof cover (accessory code: CP-200).
- CE compliant (EMC Directive 2014/30/EU)
- RoHS 3 (2015/863/EU)
- REACH SVHC compliance
| Property | Property Value |
|---|---|
| sku | 3V21006NCB-AM |
| Position | 3-Port 2-Position |
| Port Size | PT1/8 |
| Standard Voltage | DC24V |
