Airtac 3V200 Solenoid Valve 3V21006NCH-AM
2. Spool-type structure with excellent sealing properties and high responsiveness;
3. Dual-coil design features memory function (position retention upon power loss);
4. Precision-engineered internal bore reduces friction resistance, enables low activation pressure (0.15MPa) and ensures extended service life;
5. Lubrication-free operation;
6. Integrated manual override for simplified commissioning and maintenance;
7. Multiple standardized voltage options available;
8. Modular valve system compatibility with manifold bases for space-optimized installations.
Category: Solenoid Valves | Brand: AirTAC | Series: 3V200
AirTAC 3V21006NCH-AM Solenoid Valve Technical Details
- Model: 3V21006NCH-AM (3V200 Series)
- Valve type: 3/2-way normally closed, pilot-operated
- Port configuration: 1/4" BSPP (G1/4) with NPT optional
- Effective area: 23mm²
- Operating pressure range: 0.05-1.0 MPa
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Power consumption: 2.2W (DC), 3.5VA (AC)
- Response time: ≤15ms (ON/OFF)
- Seal material: Heat-resistant NBR (Nitrile) with PTFE backup rings
- Ambient temperature: -20℃ to +80℃ (no freezing)
- Fluid temperature: 0℃ to 60℃
- Protection class: IP67 (dust/water resistant)
- Housing material: Reinforced PBT with stainless steel core
- Weight: 280g ±5g (including coil)
- Dimensions: 56mm (L) × 38mm (W) × 73mm (H)
- Port thread depth: 12mm
- Max flow rate: 750 NL/min (at 0.5 MPa)
High-flow solenoid valve engineered for industrial automation systems requiring rapid cycling and extended service life. Features triple-seal construction with debris-resistant spool design, compatible with ISO 8573-1:2010 Class 3 compressed air. The anti-vibration coil assembly maintains stable operation in mobile applications.
- Pneumatic pressurization systems in semiconductor manufacturing
- High-speed packaging line diverters (200+ cycles/min)
- CNC machine tool clamping/unclamping sequences
- Wastewater treatment plant pneumatic actuators
- Food processing equipment (FDA-compliant seals)
Installation requirements:
Install with 5-7Nm torque using backup wrench flats. Requires upstream
5μm filter + 25-30μm lubricator (ISO VG32 oil mist recommended).
For horizontal mounting, orient exhaust port downward.
| Property | Property Value |
|---|---|
| sku | 3V21006NCH-AM |
| Position | 3-Port 2-Position |
| Port Size | PT1/8 |
| Standard Voltage | DC24V |
