Airtac 3V200 Solenoid Valve 3V21006NOA-AM
2. Spool-type structure with excellent sealing properties and high responsiveness;
3. Dual-coil design features memory function (position retention upon power loss);
4. Precision-engineered internal bore reduces friction resistance, enables low activation pressure (0.15MPa) and ensures extended service life;
5. Lubrication-free operation;
6. Integrated manual override for simplified commissioning and maintenance;
7. Multiple standardized voltage options available;
8. Modular valve system compatibility with manifold bases for space-optimized installations.
Category: Solenoid Valves | Brand: AirTAC | Series: 3V200
AirTAC 3V21006NOA-AM Solenoid Valve Technical Details
- Model Code: 3V21006NOA-AM (Standard Industrial Series)
- Valve Type: 3/2-way normally open (direct-acting)
- Port Thread: PT1/8" (G1/8" BSPP available on request)
- Pressure Range: 0.05–1.0 MPa (7-145 PSI)
- Voltage Variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Flow Capacity: 750 l/min (Cv=1.3 at 0.5MPa)
- Response Time: ≤15ms (exhaust to actuation)
- Body Material: Die-cast aluminum alloy (anodized finish)
- Seal Compound: Heat-resistant HNBR (-30℃ to 120℃)
- Ambient Temp: -20℃ to +80℃ (non-freezing)
- Power Consumption: 2.2W (AC), 2.6W (DC)
- Electrical Protection: IP67 (dust/water resistant)
- Weight: 185g ±5g (with connector)
- Dimensions: 53mm(L) × 34mm(W) × 67mm(H) (excluding fittings)
High-cycle solenoid valve with zero-pressure start capability, featuring brass core tube for reduced magnetic leakage. Designed for vacuum/pressure dual-use systems requiring fast switching. Includes surge protection circuit and manual override. Requires 5μm filtration with oil mist lubrication (ISO VG32 recommended).
- Textile machinery thread control systems
- Beverage filling line pneumatic actuators
- 3D printer vacuum bed clamping
- Semiconductor cleanroom equipment
- Electric vehicle battery cooling systems
Critical Note:
Requires 20% duty cycle derating when operating above 60℃. Install shock absorbers
if valve will experience vibration exceeding 5G. Lubricate seals every 5 million cycles.
| Property | Property Value |
|---|---|
| sku | 3V21006NOA-AM |
| Position | 3-Port 2-Position |
| Port Size | PT1/8 |
| Standard Voltage | AC220V |
