Airtac 3V200 Solenoid Valve 3V21006NOB-AM
2. Spool-type structure with excellent sealing properties and high responsiveness;
3. Dual-coil design features memory function (position retention upon power loss);
4. Precision-engineered internal bore reduces friction resistance, enables low activation pressure (0.15MPa) and ensures extended service life;
5. Lubrication-free operation;
6. Integrated manual override for simplified commissioning and maintenance;
7. Multiple standardized voltage options available;
8. Modular valve system compatibility with manifold bases for space-optimized installations.
Category: Solenoid Valves | Brand: AirTAC | Series: 3V200
AirTAC 3V200 Solenoid Valve 3V21006NOB-AM Technical Specifications
- Full model code: 3V21006NOB-AM
- Valve type: 3/2-way normally open (pilot-operated)
- Port configuration: PT1/4 (G1/8 optional)
- Thread standard: ISO228/1 (BSPP)
- Operating pressure range: 0.15–0.8 MPa (21.7–116 PSI)
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Power consumption: ≤2.2W (DC), ≤3.5VA (AC)
- Response time: ≤15ms (open/close cycle)
- Flow coefficient (Cv): 1.4
- Maximum air leakage: ≤30 mL/min @ 0.5MPa
- Seal material: Heat-resistant NBR (-20℃ to 80℃)
- Body material: Anodized aluminum alloy
- Protection class: IP67 (coil), IP40 (valve body)
- Vibration resistance: ≤55Hz with 1.5mm amplitude
- Shock resistance: 100m/s² (approx. 10G)
- Weight: 285g ±5g (excluding connector)
- Dimensions: 54mm(L) × 38mm(W) × 72mm(H) (excluding mounting bracket)
High-flow compact solenoid valve with anti-vibration design, featuring brass internal components for enhanced durability. The AM suffix indicates special oil-resistant seals and military-grade coil insulation. Requires 5μm filtered compressed air with ISO8573-1:2010 Class 3.2.3 air quality (max 5mg/m³ oil content).
- CNC machine tool clamping systems
- Automotive assembly line pneumatic actuators
- Plastic injection molding machine ejectors
- Food processing equipment (oil-resistant variant)
- Robotic end-effector tool changers
Installation guidelines:1. Mount with M4 screws (1.2N·m torque max)
2. Maintain ambient temperature below 60℃ with 85% RH max
3. Lubricate with ISO VG32 turbine oil if used in high-cycle applications
4. For horizontal mounting, install exhaust port downward
| Property | Property Value |
|---|---|
| sku | 3V21006NOB-AM |
| Position | 3-Port 2-Position |
| Port Size | PT1/8 |
| Standard Voltage | DC24V |
