Airtac 6TV Solenoid Valve 6TV0500M16F
2、Internal exhaust structure collects pilot gas for centralized discharge through R port;
3、Aluminum alloy extruded body with precision-machined internal bore to significantly enhance flow efficiency;
4、Optional threaded connection type for integration with valve manifolds via base mounting, saving installation space.
Category: Solenoid Valves , Brand: AirTAC , Series: 6TV
AirTAC 6TV0500M16F Solenoid Valve Technical Details
- Model: 6TV0500M16F
- Type: 5/2-way monostable (single solenoid)
- Port size: 1/4" NPT (M5x0.8 optional)
- Operating pressure range: 0.1–1.0 MPa
- Max flow capacity: 1000 l/min (ANR)
- Cv value: 1.8
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Power consumption: 2.8W (DC), 4.5VA (AC)
- Response time: ≤15ms (excitation), ≤20ms (reset)
- Weight: 320g ±5% (without connector)
- Dimensions: 58mm(L) × 45mm(W) × 86mm(H)
- Valve body material: Reinforced PBT with glass fiber
- Seal material: Heat-resistant NBR (up to 120℃ peak)
- Temperature range: -10℃ to 80℃ (non-freezing)
- Protection rating: IP67 (dust/water resistant)
- Port thread depth: 12mm (minimum engagement)
- Mounting orientation: Any (horizontal recommended for optimal drainage)
High-flow directional control valve with rugged construction for industrial automation systems. Features dual-color position indicator (red/green LED optional) and manual override function. The pilot-operated design ensures reliable switching under variable pressure conditions. Compatible with ISO 15407-1 standards.
- Pneumatic cylinder control in assembly line machinery
- Textile manufacturing equipment actuators
- Plastic injection molding machine air circuits
- Automated material handling systems
- Semiconductor manufacturing cleanroom devices
Installation guidelines:
Use anti-vibration washers when mounting on machinery with >5G vibration.
Lubricate seals with ISO VG32-grade turbine oil if operated continuously above 60℃.
Maintain minimum 85% vacuum level during suction applications.
- 500,000 cycles: Lubrication check
- 2 million cycles: Seal replacement
- 5 million cycles: Full overhaul (coil resistance test recommended)
| Property | Property Value |
|---|---|
| sku | 6TV0500M16F |
| Initial Position | Please provide the specific AirTAC product attribute values you need translated, and I will return the accurate English terminology. |
| Port Size | Please provide the specific AirTAC product attribute values you need translated, and I will return the accurate English terminology. |
| Standard Voltage | Please provide the specific AirTAC product attribute values you need translated, and I will return the accurate English terminology. |
| Type | Base |
