Airtac 6TV Solenoid Valve 6TV0500M3F
$9.73
Regular price
$17.23
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
6TV0500M3F
Product type:
Tags:
Collections:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1、Plug-in electrical connection design allows horizontal and vertical terminal mounting orientations to be freely interchangeable;
2、Internal exhaust structure collects pilot gas for centralized discharge through R port;
3、Aluminum alloy extruded body with precision-machined internal bore to significantly enhance flow efficiency;
4、Optional threaded connection type for integration with valve manifolds via base mounting, saving installation space.
Category: Solenoid Valves , Brand: AirTAC , Series: 6TV
2、Internal exhaust structure collects pilot gas for centralized discharge through R port;
3、Aluminum alloy extruded body with precision-machined internal bore to significantly enhance flow efficiency;
4、Optional threaded connection type for integration with valve manifolds via base mounting, saving installation space.
Category: Solenoid Valves , Brand: AirTAC , Series: 6TV
AirTAC 6TV0500M3F 5/2-Way Solenoid Valve Specifications
- Model: 6TV0500M3F
- Type: 5/2-way monostable (single solenoid, spring return)
- Port size: PT1/4 (G1/4 optional)
- Thread standard: ISO 228/1 (BSPP)
- Operating pressure: 0.15–0.8 MPa (21.7–116 PSI)
- Voltage options: DC12V, DC24V, AC110V(50/60Hz), AC220V(50/60Hz)
- Max flow rate: 750 l/min (ANR)
- Cv value: 1.2
- Response time: ≤25ms (at 0.5MPa)
- Seal material: NBR (Nitrile) standard, optional Viton
- Temperature range: -5℃ to 80℃ (with NBR seals)
- Weight: 310g ±5% (without coil)
- Dimensions: 52mm(W) × 38mm(H) × 88mm(L)
- Protection rating: IP65 (coil), IP40 (valve body)
- Porting pattern: ISO 5599-1 standard
- Manual override: Optional paddle-type
High-flow 5/2-way pneumatic valve with aluminum alloy body and copper-free piston design. Features double-seal structure for zero leakage, compatible with vacuum applications (0.15–0.8 MPa). Optimized flow path reduces pressure drop by 15% compared to previous generation models.
Industrial Applications:
- Automated assembly line actuators
- Plastic injection molding machines
- Textile machinery cylinder control
- Material handling systems
- Die-casting equipment
- Pneumatic clamping devices
Installation requirements:
Install in vibration <50Hz environment. Use 5μm filtration (40μm for vacuum).
Lubrication not required but compatible with ISO VG32 oil mist. Allow 30mm
maintenance clearance above solenoid coil.
| Property | Property Value |
|---|---|
| sku | 6TV0500M3F |
| Initial Position | Please provide the specific AirTAC product attribute values you need translated, and I will return the accurate English terminology. |
| Port Size | Please provide the specific AirTAC product attribute values you need translated, and I will return the accurate English terminology. |
| Standard Voltage | Please provide the specific AirTAC product attribute values you need translated, and I will return the accurate English terminology. |
| Type | Base |
