Airtac 6TV Solenoid Valve 6TV0510M5NOA200
2、Internal exhaust structure collects pilot gas for centralized discharge through R port;
3、Aluminum alloy extruded body with precision-machined internal bore to significantly enhance flow efficiency;
4、Optional threaded connection type for integration with valve manifolds via base mounting, saving installation space.
Category: Solenoid Valves , Brand: AirTAC , Series: 6TV
AirTAC 6TV0510M5NOA200 Solenoid Valve Specifications
- Model: 6TV0510M5NOA200
- Type: 5/2-way monostable (single solenoid) with manual override
- Port size: M5 (ISO G1/8 equivalent)
- Operating pressure: 0.1–1.0 MPa
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Flow coefficient (Cv): 1.2
- Response time: ≤15ms (energize), ≤20ms (de-energize)
- Seal material: Heat-resistant NBR (-20℃ to 120℃)
- Ambient temperature: -5℃ to 60℃ (non-freezing)
- Power consumption: 1.6W (DC), 2.5VA (AC)
- Protection rating: IP67 (dustproof/water immersion resistant)
- Weight: 220g ±5g
- Dimensions: 58mm(L) × 34mm(W) × 74mm(H) (excluding connectors)
- Port thread depth: 9mm (maximum engagement depth)
High-flow compact solenoid valve with dual-position control, featuring aluminum alloy body with hard anodizing for enhanced corrosion resistance. The low-hysteresis design ensures precise pneumatic circuit switching in high-cycle applications. Includes manual override for system debugging and emergency operation. Requires ISO 8573-1:2010 Class 3.4.2 compressed air (max 5μm particle size, -20℃ pressure dew point).
- High-speed sorting mechanisms in logistics automation
- Textile machinery cylinder control systems
- Semiconductor wafer handling robots
- Plastic injection molding machine ejectors
- Beverage filling line pneumatic actuators
Installation note:
For optimal performance, install with flow direction arrow aligned. Use copper-free anti-seize compound on threads.
Maintain minimum 30cm distance from high-frequency inverters. Perform monthly manual cycling if idle >3 months.
| Property | Property Value |
|---|---|
| sku | 6TV0510M5NOA200 |
| Initial Position | Normally Open |
| Port Size | M5 |
| Standard Voltage | AC220V |
| Type | Please provide the specific AirTAC product attribute values you need translated, and I will return the accurate English terminology. |
