Airtac 7V Solenoid Valve 7V0510J04A200
2. Internal exhaust structure collects pilot gas and discharges centrally through R/S ports;
3. Aluminum alloy die-casting body with optimized flow path design enhances flow capacity;
4. Available in threaded or quick-connect versions, compatible with manifold base integration for space-saving installation.
Category: Solenoid Valves, Brand: Airtac, Series: 7V
AirTAC 7V0510J04A200 Solenoid Valve Specifications
- Model: 7V0510J04A200
- Type: 5/2-way monostable (spring return)
- Port configuration: 5 ports (P, A, B, EA, EB) / 2 positions
- Port size: PT1/4 (G1/4 optional)
- Thread standard: ISO228/1 (BSPP)
- Operating pressure: 0.15–0.8 MPa (21.7–116 psi)
- Proof pressure: 1.2 MPa
- Voltage tolerance: ±10% (rated voltage)
- Voltage options: DC24V (±10%), AC110V 50/60Hz, AC220V 50/60Hz
- Coil insulation class: Class F (155℃)
- Response time: ≤15ms (energized), ≤20ms (de-energized)
- Flow capacity: 850 l/min (Cv=1.3)
- Seal material: Heat-resistant NBR (-20℃ to 80℃)
- Body material: Aluminum alloy with hard anodizing
- Weight: 0.45 kg (0.99 lb)
- Dimensions: 70mm(L) × 45mm(W) × 100mm(H)
- Protection rating: IP65 (coil)/IP40 (valve body)
- Service life: ≥10 million cycles
- Ambient temperature: -5℃ to 60℃ (non-freezing)
- Installation orientation: Any (prefer vertical)
High-flow 5/2-way solenoid valve with compact modular design, featuring low power consumption (2.5W max) and dust-resistant metal body. The pilot-operated structure ensures reliable switching even under pressure fluctuations. Optimized flow path reduces air turbulence for stable cylinder control. Requires 5μm filtered lubricated air (ISO8573-1 class 4).
- Double-acting cylinder control in automation lines
- Pneumatic clamping systems in CNC machines
- Material handling equipment position switching
- Textile machinery air circuit control
- Automotive assembly line actuators
Maintenance tip:
Lubricate air supply monthly (ISO VG32 oil mist 1 drop/m³).
For horizontal mounting, install exhaust silencers vertically downward
to prevent condensation accumulation. Maximum allowable vibration: 10-55Hz, 1.5mm amplitude.
| Property | Property Value |
|---|---|
| sku | 7V0510J04A200 |
| Port Size | PT 1/2 |
| Standard Voltage | AC220V |
