Airtac 7V Solenoid Valve 7V0510J04B050
2. Internal exhaust structure collects pilot gas and discharges centrally through R/S ports;
3. Aluminum alloy die-casting body with optimized flow path design enhances flow capacity;
4. Available in threaded or quick-connect versions, compatible with manifold base integration for space-saving installation.
Category: Solenoid Valves, Brand: Airtac, Series: 7V
AirTAC 7V0510J04B050 Solenoid Valve Technical Details
- Model: 7V0510J04B050
- Valve type: 5/2-way single solenoid (pilot-operated)
- Port size: PT1/4 (G1/8 optional)
- Operating pressure: 0.1–0.8 MPa (14.5–116 PSI)
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Max flow rate: 750 l/min (ANR) at 0.5 MPa
- Seal material: Heat-resistant NBR (Nitrile) with PTFE coating
- Ambient temperature: -5℃ to 80℃ (with 0.5mm dust shield)
- Response time: ≤18ms (energize)/≤15ms (de-energize)
- Duty cycle: 100% continuous operation rated
- Protection class: IP67 (dust/water resistant)
- Weight: 215g ±5g (including connector)
- Dimensions: 62mm(L) × 35mm(W) × 75mm(H) (manual override protrusion excluded)
- Port thread depth: 9.5mm (ensures secure fitting)
- Coil insulation class: F-class (155℃)
- Hysteresis: ≤0.05 MPa (pressure differential stability)
High-flow proportional control valve with reinforced pilot mechanism, featuring dual-chamber sealing technology for zero-leakage performance. The hardened aluminum alloy body withstands vibration up to 20Hz/2G. Includes manual override button for system debugging and emergency control. Requires 5μm filtered dry air with ISO 8573-1:2010 class 4.4.3 standards.
- Automated assembly line actuator clusters
- Plastic injection molding machine ejectors
- CNC tool changers with rapid cycling
- Beverage filling systems requiring sanitary flow control
- Lithium battery production dry room equipment
Mounting protocol:
Install with vibration-damping brackets in high-shock environments.
Maintain 15mm clearance from adjacent components for heat dissipation.
Lubricate O-rings with silicone grease (Parker #OX-222) during maintenance.
| Property | Property Value |
|---|---|
| sku | 7V0510J04B050 |
| Port Size | PT 1/2 |
| Standard Voltage | DC24V |
