Airtac 7V Solenoid Valve 7V0510J04C050
2. Internal exhaust structure collects pilot gas and discharges centrally through R/S ports;
3. Aluminum alloy die-casting body with optimized flow path design enhances flow capacity;
4. Available in threaded or quick-connect versions, compatible with manifold base integration for space-saving installation.
Category: Solenoid Valves, Brand: Airtac, Series: 7V
AirTAC 7V0510J04C050 Solenoid Valve Technical Details
- Model: 7V0510J04C050
- Type: 5-port/3-position closed center (Double solenoid)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure: 0.1–0.9 MPa
- Voltage variants: DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Flow capacity: 850 L/min (Cv=1.3)
- Response time: ≤20ms (actuation), ≤30ms (release)
- Valve body material: Reinforced PBT resin
- Seal material: Heat-resistant NBR (-20℃ to 120℃)
- Weight: 420g ±5%
- Dimensions: 54mm(L) × 48mm(W) × 84mm(H)
- Protection rating: IP67 (dust/water resistant)
- Port thread depth: 12mm (with O-ring seal)
- Manual override: Built-in emergency switch
High-flow directional control valve optimized for complex pneumatic circuits requiring mid-stability. Features dual-coil latching design for energy efficiency and position memory. Includes surge suppression diodes for electrical protection. Requires 5μm filtered lubricated air (ISO 8573-1 class 4).
- Automated assembly line clamping systems
- Plastic injection molding machine actuators
- Beverage filling station cylinder control
- Lithium battery production vacuum circuits
- Semiconductor handling robotics
Installation guidelines:
Mount with vibration-damping brackets in high-shock environments.
Maintain minimum 15mm clearance around exhaust ports. Lubricate
every 2M cycles using ISO VG32 pneumatic oil.
- Mounting base: SY5120 series
- Quick-connect fittings: QSME-02-00
- Fieldbus control: FESTO CPX adapter (optional)
| Property | Property Value |
|---|---|
| sku | 7V0510J04C050 |
| Port Size | PT 1/2 |
| Standard Voltage | AC 110V |
